2014 Hot New LED Modules 0.24w~15w China Shenzhen Factory

Specifications

1)CE, RoHS, IP65
2)Constant current driving IC
3)Pure Aluminum PCB
4)high power with optic lens
5)3~5 years warranty

CREE LED Modules for sign lighting



What is the story of ZOYO LED?

Here office stuffs, workers came for two men who worked in MRSON for 11 years in LED Packaging and in LBY for 12 years as R&D Director in LED modules. Here they know each other for years before cooperation. Here most of them have worked here, lived here with families. Here they do not ask for leave except any emergency. Here awards and punishments are clear for everyone. Here they are working as a group, taking 100% responsibility avoids management costs.

.

It’s Company Attitudes: Innovation, Value, Integrity, Gratitude.

It’s Company Missions: offering customers the most competitive products, technical support, no delay delivery, instant after sales services.



What are the details of high power LED module MD451S-W1?



No.	Items	Parameters
1.	Product No.	MD451S-W1
2	Size	52*30*7.6mm
3	LED	Higher power SMD LED 3W
4	Drive type	Constant current driving IC
5	Input voltage	DC12V
6	Input Current	0.25A
7	Power	3W
8	Luminous Flux	295 lm
9	Color Temperature	6000K
10	Beam angle	160 degree
11	IP rate	IP65
12	Structure & material	Pure Aluminum PCB, ABS/ PVC process, PMMA optic lens
13	Warranty	5 years warranty
14	Quick Delievery	1-10days
15	Certificate	CE/ROHS
16	Working temperature	-40~+60°C
17	Stock temperature	-50~+60°C
18	Wire distance	187mm
19	QTY. /Square meter	8-12pcs
20	Application	advertising signs / channel letters / light boxes, and etc..
21	Other	ODM service available



Product Photo:





Product Structure:





Packaging, Shipping &Trading Terms:

Packaging:



Shipping:

1.FedEx/DHL/UPS/Russian express/ARAMEX for samples, Door-to-Door.

2.Delivery by customer's own forwarder.

Trading Terms:
T/T, Western Union, PayPal, irrevocable L/C at sight; 30% deposit for starting production.



Why choose us?

1.We are Alibaba Assessed Gold Supplier.

2.We are a factory professional manufacturing Injection molding LED modules with large production capability, ISO9001:2008 quality control system, instant services..

3.We have our own R&D engineers’ team, best product innovation capabilities.

4.100% QC inspection before shipment.

5. factory direct sales, competitive price.





 Where do ZOYO LED modules apply for?







1.Advertising signs, LOGO & Channel letters backlight,



2.Light source for advertising boxes  or cabines.



3.And etc..









What are the most popular LED modules?



Product Name	Item No.	Power	Color Tempreture	Size	Remark
Bee Series	MA221B-W	0.36w	6000K	22*10*4.8mm	Backlit
Bee Series	MA743B-W	0.6w	6000K	74*12*4.8mm	Backlit
Bee Series	MA743C-W	1.2w	6000K	74*12*4.8mm	Backlit
Tiger Series	MA301F-W	0.6w	6000K	30*18*6.4mm	Backlit
Tiger Series	MA542F-W	1.2w	6000K	54*18*6.4mm	Backlit
Tiger Series	MA823F-W	1.5w	6000K	82*18*7.2mm	Backlit
Tiger Series	MA484F-W	2w	6000K	48*36*6.4mm	Backlit
Loong Series	MH401F-C(W)	1.5w	9000K	40*28*7.4mm	Backlit
		1.2w	6000K
CREE XBD LED	ML521S-W	2w	6000K	52*28*7.4mm	Backlit
Eagle Series	MD401S-W	1.2w	6000K	40*35*15mm	Edge light
Eagle Series	MD451S-W	2w	6000K	45*35*15mm	Edge light
CREE XBD LED	ML521S-W	2w	6000K	52*35*15mm	Edge light
CREE XBD LED	ML273S-W	9w	6000K	275*26*15mm	Edge light
CREE XBD LED	ML495S-W	15w	6000K	475*26*15mm	Edge light











Company View:











CE, ROHS certificate:





Our Exhibitions:





FAQ



Q1: Can I have free samples to test?

A1: Yes, free samples available for your test with freight collect or prepaid by Paypal or Western Union. .



Q2: How can I test samples?

A1: Connect the modules with your own power supply whose output voltage should be DC12V or DC24V. If you do not have such a power supply, please ask us to provide with samples.



What is the Warranty for your modules?

A2: For the modules, we have 3 years warranty for modules with Samsung, Epistar or Sanan LED, 5 years warranty for Cree or Osram LED. If any product problems occurred during warranty, we take responsibility to send you replacements immediately.



Q3: What are the advantages of constant current circuit driving?

A3: Constant current driving ensuring full string working in same brightness and stably working, greatly reduce the fluctuating power efficiency and maintain longer lifespan of LEDs.



Q4: Do you also sell power supplies or extra collectors for the modules?

A4: Yes. But please take care that power supply should leave some capacity to protect itself and modules with 20%~30% unused. i.e. input power are 20%~30% more than exact LEDs power consumption.



Q5: What is the max quantity of one string?

A5: Normally we suggest max 20pcs a string then connect to power supply, but if you have other requests. Please contact us for more information.



Q6: Are your LED modules dimmable?

A6: Most of our LED modules are not dimmable. We now just do ODM products for regular customers.



Q7: Can I use the modules in outdoor or directly opening conditions?

A7: Modules’ Protection rate is IP65, but better be used in lights boxes, channel letters or carbines in outdoor projects and avoid being exposed to opening conditions.



Q8: Do you accept OEM/ODM service?

A8: Yes, lead time for sample is around 3 days and for bulk order needs around 3 weeks.



Q9: Is there any cheap shipping method to import to our country?

A9: For small order, express will be best. And for bulk order, shipment by sea is the cheapest way but take much time.
For urgent orders, we suggest DHL or Fedex IP with door to door service.

Kindly be assure we will always check the best shipping way for you.



Q10: Can we get a good price for your high power modules, as we sell low power module most at present?



A10: Please inform us your detailed mind on your market demand, we will discuss and propose helpful suggestion for you, to find the best solution for you.



Q11: Can you tell me the differences between your modules with and without optic lens?

A11: Kindly note the reason that optic lens occurs is to avoid brighter dots and to get evenly light effect. As LED modules would be the perfect light source for advertising signs, we design lens for modules suitable for various applications



How to contact Us?

Contact via Trade Manager ID: cn1511651355 or write down your inquiry in the below blank column, and Click "Send"Now! Free samples are waiting for you.



Hope ZOYO LED and bellow Monkoon Jou have the honor to support you well in future!
