Help CenterSensor CMOS 1 Mega Pixels Fisheye ip CameraHD264
Related Products
-
2014 the Hotest Product Sensor CMOS 5 Mega Pixels Wifi Ptz Outdoor Dome ip Camera HD264US$ 20 - 60MOQ: 5 Pieces -
Sensor CMOS 1 Mega Pixels Wifi Ptz Outdoor Dome ip Camera HD264US$ 20 - 60MOQ: 5 Pieces
-
Sensor CMOS 1 Mega Pixels Solar Powered Wireless Outdoor ip Camera HD264US$ 20 - 60MOQ: 5 Pieces
-
2014 the Hotest Product Sensor CMOS 5 Mega Pixels Solar Powered Wireless Outdoor ip Camera HD264US$ 20 - 60MOQ: 5 Pieces
-
Sensor CMOS 1 Mega Pixels Convert Analog Cctv to ip Camera HD264US$ 20 - 60MOQ: 5 Pieces
Specifications
1.pixels high2.high-end grade atmosphere
3.Exquisite wokemanship
4.all these are new models
forable, Noble symbol
Resolution ratio: 720P(1280*720),VGA(640*480),QVGA(320*240)
Filter switch:Built-in IR-Cut, filter switch automatically, without color cast
Night vision:12 Φ5 LED lights IR distance: 15m
PTZ Rotation angle:Horizontal: 355° vertical: 120°
PTZ preset:support 16 preset
Maximal online users:Main code flow support 5 user, Minor code flow support 6 user
Audio Input:Linear input / Microphone input / audio output
Alarm Input/output:Trigger level (low level, high level), PTZ linkage/alarm output
Alarm detection:Motion detection
Detection area:Support 4 detection area
Alarm notification:E-Mail notification, save the recording and picture to TF card, save the picture to FTP
System |
System security |
Three operating privileges, different users can set upf different operating authority |
DDNS domain |
Provides DDNS system free,come with special domain, |
|
Mobile access |
Android and Apple software monitoring. |
|
Motion alarm |
Supports 4 motion detection area maximum,can set up alarm interval, also can set up Occluded region, Occluded region video not visible to users. |
|
Local-storage |
Supports 32GB MicroSD Card,Loop-recording 24 hours one day. |
|
Others |
Set up OSDtime/device name: dynamic adjustment frame rate, code rate, Supports fixed code stream and dynamic code stream |
|
System kenel |
Operating |
Embedded Linuxoperating system |
|
||
network |
Network port |
|
Networking protocal |
HTTP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP |
|
WIFI |
Wifi802.11 b/g/n |
|
IP Address |
Static IP address,dynamic IPaddress,PPPOE dial |
|
Online users maximum |
Main code stream:5 users online at the same |
|
secondary code stream:6 users online at the same | ||
video |
compression mode |
H.264 Basline Profile@Level 1-4.1 |
Sensing device |
1/4inch Mega pixel CMOS imaging sensor |
|
CMOS property |
Auto white balance,auto gain control,Auto backlight compensation |
|
Mini illumination |
color:0.3 Lux at F1.6 B/W:0 lux led on |
|
lens |
standard:3.6mm board lens /F1.6 Mega pixel with IR_CUT |
|
Frame rate |
1~30frame |
|
resolution |
720P(1280*720),VGA(640*480),QVGA(320*240) optional |
|
Picture control |
brightness,contrast adjustment |
|
|
White balance& backlight compensation |
Auto white balance |
|
Mini illumination |
0.1LUX/F1.2 |
|
SNR |
>48dB |
|
Night vision |
Light filter |
|
Night vision |
|
|
audio |
Compression mode |
G.711 format |
input |
Microphone input |
|
output |
Audio output |
|
PTZ |
motor |
Built-in motor |
Rotation angle |
horizontal:355 degree,vertical:120 degree |
|
Presetting bit |
16pcs |
|
PTZ protocal |
Pelco-D |
|
PTZ speed |
Horizontal speed:90°/second, vertical speed:90°/second |
|
Alarm |
Input/output |
Triggering level(low level,high level),PTZ ganged/alarm output |
Motion detection |
4 areas optional,can set up sensitivity motion detection |
|
Surveyed area |
4 areas surveyed area |
|
Alarm notice |
Supports client-side triggering recording,send E-mail,photos upload FTP server |
|
