High Quality CE ROHS Blue 1206 SMD Led
US$ 0.018 - 0.019
MOQ: 3000 Pieces
Key Specifications
Get Latest Price
Model Number:
FD-1206B
Chip Material:
InGaN
Emitting Color:
Blue
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Brightness 588-595nm Yellow 1206 SMD LedUS$ 0.014 - 0.015MOQ: 3000 Pieces -
High Quality CE ROHS High Brightness White Diode 1206 SMD LedUS$ 0.014 - 0.015MOQ: 3000 Pieces
-
Highest Quality 110-130lm White EMC 3030 SMD Led Chip 1w 3v 6vUS$ 0.059 - 0.079MOQ: 4000 Pieces
-
High Quality CE ROHS High Brightness 620-625nm Red 1206 SMD Led DiodeUS$ 0.011 - 0.012MOQ: 3000 Pieces
-
SMD Led 3528 Blue ChipNegotiableMOQ: 4000 Pieces
Model Number
FD-1206B
Chip Material
InGaN
Emitting Color
Blue
Luminous Intensity
180-250mcd
Luminous Flux(lm)
180-250mcd
Optical Attenuation(%)
0.001%
Power
Other, 0.086w
Power Dissipation
70
Color Rendering Index(Ra)
80
Color Temperature
B:460-470nm
Operating Temperature(℃)
-40, +80
Storage Temperature(℃)
-40, +80
Place of Origin
Guangdong, China
Brand Name
FEDY
Certification
CE
High quality CE ROHS Blue 1206 SMD led
Product Description
High quality CE ROHS Blue 1206 SMD led
| Part No. | Color | Wavelength/ CCT |
Intensity | Emitting angle |
| FD-1206W | White | 2500K up to 20000K | 700-800mcd | 120degree |
| FD-1206R | Red | 620-630nm | 100-200mcd | 120degree |
| FD-1206Yg | Yellowgreen | 568-574nm | 30-50mcd | 120degree |
| FD-1206Y | Yellow | 588-595nm | 100-150mcd | 120degree |
| FD-1206O | Orange | 600-610nm | 100-200mcd | 120degree |
| FD-1206B | Blue | 460-470nm | 180-250mcd | 120degree |
| FD-1206G | Green | 520-525nm | 600-800mcd | 120degree |
| FD-1206Pi | Pink | X0.38 Y0.108 | 120-150mcd | 120degree |
| FD-1206Pu | Purple | 395-400nm | 80-100mcd | 120degree |
1. Epistar chips
2. Brightest version
3. SUper low decay
4. Lifespan > 80 000hours
5. Warranty : 3 years
6. Anti-static built in
7. Anti-high temperature
8. 100% tested , binned by automatic machine before QC QA test
Packaging & Shipping
3000pcs per Reel
20esd bags per CTN
Shipping : International express DHL , UPS ,,,etc
By Air
By sea
By your agent
Our Services
1. Highest quality .
2. Best price
3. Fast delivery
4. Well packed
Company Information
Fedy is a LED component manufacturer since 2000. All efforts focused on high quality led component .
High cost performance won't let you disappointed .
| Part No. | Color | Wavelength/ CCT |
Intensity | Voltage |
| FD-0603W | White | 2500K up to 20000K | 9-16lm | 3.0-3.2V |
| FD-0603B-1 | Blue | 460-470nm | 200-300mcd | 3.0-3.2V |
| FD-0603G-1 | Green | 520-525nm | 500-800mcd | 3.0-3.2V |
| FD-0603R-1 | Red | 620-630nm | 200-300mcd | 1.9-2.3V |
| FD-0603B-2 | Blue | 460-470nm | 300-500mcd | 3.0-3.2V |
| FD-0603G-2 | Green | 520-525nm | 800-1500mcd | 3.0-3.2V |
| FD-0603R-2 | Red | 620-630nm | 300-500mcd | 1.9-2.3V |
| FD-0603Y | Yellow | 588-595nm | 200-300mcd | 1.9-2.3V |
| FD-0603A | Amber | 600-610nm | 200-300mcd | 1.9-2.3V |
| FD-0603IR | Infrared | 940nm | 1.5-1.7 | |
| FD-0603IR2 | Infrared | 850nm | 1.5-1.7 | |
| FD-0603UV | UV | 395-400 400-405 | 3.2-3.6 | |
| FD-0603Pi | Pink | 3.0-3.4 |
| Item | Part No. | Wavelength/CCT | Intensity | Voltage | Power |
| SMD5050 white | FD-5050W-1 | 5500-6000k | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050W-2 | 6000-6500k | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050W-3 | 6500-7000k | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050W-4 | 7000-7500k | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050W-5 | 7500-8000k | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 reddish white | FD-5050RW-1 | 2000-2400K | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050RW-2 | 2400-2700k | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 Yellowish white | FD-5050YW-1 | 2800-3200K | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050YW-2 | 3200-3500K | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 cool white | FD-5050CW-1 | 8000-9000K | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050CW-2 | 9000-10000K | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050CW-3 | 10000-12000K | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050CW-4 | 12000-15000K | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050CW-5 | 20000-25000K | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 blue | FD-5050B | 460-470nm | 1000-3500mcd | 3.0-3.5v | 0.18W |
| SMD5050 Amber | FD-5050A | 600-610nm | 1000-3500mcd | 1.9-2.2V | 0.12W |
| SMD5050 Green | FD-5050G | 520-525nm | 2500-5500mcd | 3.0-3.5v | 0.18W |
| SMD5050 Yellow | FD-5050Y | 588-595nm | 1200-3500mcd | 1.9-2.2V | 0.12W |
| SMD5050 Red | FD-5050R | 620-625nm | 1200-3500mcd | 1.9-2.2V | 0.12W |
| SMD5050 RGB | FD-5050RGB | R:350-450MCD B:250-300MCD G:900-1100MCD |
|||
| Item | Part No. | Wavelength/CCT | Intensity | Voltage | Power |
| SMD3528 white | FD-3528W-1 | 5500-6000k | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528W-2 | 6000-6500k | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528W-3 | 6500-7000k | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528W-4 | 7000-7500k | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528W-5 | 7500-8000k | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 reddish white | FD-3528RW-1 | 2000-2400K | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528RW-2 | 2400-2700k | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 Yellowish white | FD-3528YW-1 | 2800-3200K | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528YW-2 | 3200-3500K | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 cool white | FD-3528CW-1 | 8000-9000K | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528CW-2 | 9000-10000K | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528CW-3 | 10000-12000K | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528CW-4 | 12000-15000K | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528CW-5 | 20000-25000K | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 blue | FD-3528B | 460-470nm | 300-600mcd | 3.0-3.5v | 0.06W |
| SMD3528 Amber | FD-3528A | 600-610nm | 300-500mcd | 1.9-2.2V | 0.04W |
| SMD3528 Green | FD-3528G | 520-525nm | 400-2000mcd | 3.0-3.5v | 0.06W |
| SMD3528 Yellow | FD-3528Y | 588-595nm | 300-500mcd | 1.9-2.2V | 0.04W |
| SMD3528 Red | FD-3528R | 620-625nm | 200-500mcd | 1.9-2.2V | 0.04W |
| SMD3528 RGB | FD-3528RGB | R:350-450MCD B:250-300MCD G:900-1100MCD |
| 1. Absolute Maximum Ratings (Ta=25°C) | |||
| Item | Symbol | Absolute Maximum Rating | Unit |
| Forward Current | IF | 350 | mA |
| Pulse Forward Current | IFP | 700 | mA |
| Allowable Reverse Current | IR | 10 | uA |
| Power Dissipation | PD | 1 | W |
| Operating Temperature | Topr | -30~+85 | °C |
| Dice Temperature | Tstg | -40~+100 | °C |
| Soldering Temperature | Tsod | 260 | °C |
| Part No. | Color | Wavelength/ CCT |
Intensity | Voltage |
| FD-3014W-A | White | 2500K up to 20000K | 9-16lm | 3.0-3.2V |
| FD-3014B | Blue | 460-470nm | 300-600mcd | 3.0-3.2V |
| FD-3014G | Green | 520-525nm | 1600-2000mcd | 3.0-3.2V |
| FD-3014R | Red | 620-630nm | 200-500mcd | 1.9-2.3V |
| FD-3014Y | Yellow | 588-595nm | 300-500mcd | 1.9-2.3V |
| FD-3014A | Amber | 600-610nm | 300-500mcd | 1.9-2.3V |
| FD-3014IR | Infrared | 940nm | 3.2-3.4V | |
| FD-3014IR2 | Infrared | 850nm | 3.2-3.4V | |
| Part No. | Color | Wavelength/ CCT |
Intensity | Watt available |
| FD-2835W-0.1 | White | 2500K up to 20000K | 12-14lm | 0.1W |
| FD-2835W-0.2 | White | 21-28lm | 0.2W | |
| FD-2835W-0.5 | White | 50-65lm | 0.5w | |
| FD-2835B | Blue | 460-470nm | / | 0.1w 0.2w 0.5w |
| FD-2835G | Green | 520-525nm | / | |
| FD-2835R | Red | 620-630nm | / | |
| FD-2835Y | Yellow | 588-595nm | / | |
| FD-2835A | Amber | 600-610nm | / | |
| FD-2835IR | Infrared | 940nm | ||
| FD-2835IR2 | Infrared | 850nm | ||
| Part No. | Color | Wavelength/ CCT |
Intensity | Watt avaialble |
| FD-5630W-A | White | 2500K up to 20000K | 40-45lm | 0.5w |
| FD-5630W-B | White | 45-50lm | ||
| FD-5630W-C | White | 50-55lm | ||
| FD-5630W-D | White | 55-60lm | ||
| FD-5630W-E | White | 60-65lm | ||
| FD-5630B | Blue | 460-470nm | / |
0.2w 0.5w |
| FD-5630G | Green | 520-525nm | / | |
| FD-5630R | Red | 620-630nm | / | |
| FD-5630Y | Yellow | 588-595nm | / | |
| FD-5630A | Amber | 600-610nm | / | |
| FD-5630IR | Infrared | 940nm | ||
| FD-5630IR2 | Infrared | 850nm | ||
| Part No. | Color | Wavelength/ CCT |
Intensity | Watt avaialble |
| FD-5730W-A | White | 2500K up to 20000K | 40-45lm | 0.5w |
| FD-5730W-B | White | 45-50lm | ||
| FD-5730W-C | White | 50-55lm | ||
| FD-5730W-D | White | 55-60lm | ||
| FD-5730W-E | White | 60-65lm | ||
| FD-5730B | Blue | 460-470nm | / |
0.2w 0.5w |
| FD-5730G | Green | 520-525nm | / | |
| FD-5730R | Red | 620-630nm | / | |
| FD-5730Y | Yellow | 588-595nm | / | |
| FD-5730A | Amber | 600-610nm | / | |
| FD-5730IR | Infrared | 940nm | ||
| FD-5730IR2 | Infrared | 850nm |
| SMD3528 | ||||
| Part No. | Color |
Wavelength/ CCT |
Intensity | Voltage |
| FD-3528W-A |
Pure white : 5500-8000K Reddish Warm white : 2000-2700K Yellowish Warm white : 2800-3500K Cool White : 8000-25000K |
3-5lm | 3.0-3.2V | |
| FD-3528W-B | 5-6lm | 3.0-3.2V | ||
| FD-3528W-C | 6-7lm | 3.0-3.2V | ||
| FD-3528W-D | 7-8lm | 3.0-3.2V | ||
| FD-3528B | Blue | 460-470nm | 300-600mcd | 3.0-3.2V |
| FD-3528G | Green | 520-525nm | 400-2000mcd | 3.0-3.2V |
| FD-3528R | Red | 620-630nm | 200-500mcd | 1.9-2.3V |
| FD-3528Y | Yellow | 588-595nm | 300-500mcd | 1.9-2.3V |
| FD-3528A | Amber | 600-610nm | 300-500mcd | 1.9-2.3V |
| FD-3528IR | Infrared | 850nm | 3.2-3.4V | |
| SMD5050 | ||||
| Part No. | Color |
Wavelength/ CCT |
Intensity | Voltage |
| FD-5050W-A |
Pure white : 5500-8000K Reddish Warm white : 2000-2700K Yellowish Warm white : 2800-3500K Cool White : 8000-25000K |
10-12lm | 3.0-3.4V | |
| FD-5050W-B | 14-16lm | 3.0-3.4V | ||
| FD-5050W-C | 16-18lm | 3.0-3.4V | ||
| FD-5050W-D | 18-21lm | 3.0-3.4V | ||
| FD-5050B | Blue | 460-470nm | 1000-3500mcd | 3.0-3.2V |
| FD-5050G | Green | 520-525nm | 2500-5500mcd | 3.0-3.2V |
| FD-5050R | Red | 620-630nm | 1200-3500mcd | 1.9-2.3V |
| FD-5050Y | Yellow | 588-595nm | 1200-3500mcd | 1.9-2.3V |
| FD-5050A | Amber | 600-610nm | 1000-3500mcd | 1.9-2.3V |
| FD-5050IR | Infrared | 850nm | 3.2-3.4V | |
| Item | Part No. | Wavelength/CCT | Intensity | Voltage | Power |
| SMD5050 white | FD-5050W-1 | 5500-6000k | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050W-2 | 6000-6500k | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050W-3 | 6500-7000k | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050W-4 | 7000-7500k | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050W-5 | 7500-8000k | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 reddish white | FD-5050RW-1 | 2000-2400K | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050RW-2 | 2400-2700k | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 Yellowish white | FD-5050YW-1 | 2800-3200K | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050YW-2 | 3200-3500K | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 cool white | FD-5050CW-1 | 8000-9000K | 14-20LM | 3.0-3.5v | 0.18W |
| FD-5050CW-2 | 9000-10000K | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050CW-3 | 10000-12000K | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050CW-4 | 12000-15000K | 14-20LM | 3.0-3.5v | 0.18W | |
| FD-5050CW-5 | 20000-25000K | 14-20LM | 3.0-3.5v | 0.18W | |
| SMD5050 blue | FD-5050B | 460-470nm | 1000-3500mcd | 3.0-3.5v | 0.18W |
| SMD5050 Amber | FD-5050A | 600-610nm | 1000-3500mcd | 1.9-2.2V | 0.12W |
| SMD5050 Green | FD-5050G | 520-525nm | 2500-5500mcd | 3.0-3.5v | 0.18W |
| SMD5050 Yellow | FD-5050Y | 588-595nm | 1200-3500mcd | 1.9-2.2V | 0.12W |
| SMD5050 Red | FD-5050R | 620-625nm | 1200-3500mcd | 1.9-2.2V | 0.12W |
| SMD5050 RGB | FD-5050RGB | R:350-450MCD | |||
| B:250-300MCD | |||||
| G:900-1100MCD | |||||
| Item | Part No. | Wavelength/CCT | Intensity | Voltage | Power |
| SMD3528 white | FD-3528W-1 | 5500-6000k | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528W-2 | 6000-6500k | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528W-3 | 6500-7000k | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528W-4 | 7000-7500k | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528W-5 | 7500-8000k | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 reddish white | FD-3528RW-1 | 2000-2400K | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528RW-2 | 2400-2700k | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 Yellowish white | FD-3528YW-1 | 2800-3200K | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528YW-2 | 3200-3500K | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 cool white | FD-3528CW-1 | 8000-9000K | 4-7LM | 3.0-3.5v | 0.06W |
| FD-3528CW-2 | 9000-10000K | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528CW-3 | 10000-12000K | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528CW-4 | 12000-15000K | 4-7LM | 3.0-3.5v | 0.06W | |
| FD-3528CW-5 | 20000-25000K | 4-7LM | 3.0-3.5v | 0.06W | |
| SMD3528 blue | FD-3528B | 460-470nm | 300-600mcd | 3.0-3.5v | 0.06W |
| SMD3528 Amber | FD-3528A | 600-610nm | 300-500mcd | 1.9-2.2V | 0.04W |
| SMD3528 Green | FD-3528G | 520-525nm | 400-2000mcd | 3.0-3.5v | 0.06W |
| SMD3528 Yellow | FD-3528Y | 588-595nm | 300-500mcd | 1.9-2.2V | 0.04W |
| SMD3528 Red | FD-3528R | 620-625nm | 200-500mcd | 1.9-2.2V | 0.04W |
| SMD3528 RGB | FD-3528RGB | R:350-450MCD | |||
| B:250-300MCD | |||||
| G:900-1100MCD |
| FD-5630W-A | 4000-5000-6000-7000K | 40-45lm | 3.0-3.2V | |
| FD-5630W-B | 45-50lm | 3.0-3.2V | ||
| FD-5630W-C | 50-55lm | 3.0-3.2V | ||
| FD-5630W-D | 55-60lm | 3.0-3.2V | ||
| Part No. | Color | Wavelength/ CCT |
Intensity | Voltage |
| FD-3014W-A | 4000-5000-6000-7000K | 9-11lm | 3.0-3.2V | |
| FD-3014W-B | 11-12lm | 3.0-3.2V | ||
| FD-3014W-C | 12-14lm | 3.0-3.2V | ||
| FD-2835W-A | 4000-5000-6000-7000K | 12-14lm | 0.1W | |
| FD-2835W-B | 21-23lm | 0.2W | ||
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
2011
Factory Size
1,000-3,000 square meters
Total Employees
201 - 300 People
You May Also Like
-
Factory Direct Surface Mount Package Type Sk6812-WWA 5050 SMD LED With IC InsideUS$ 0.09 - 1MOQ: 1000 Pieces
-
Programmable Rgb APA102 2020 Smart Led LC8822 SMD2020 Rgb Smd LED Chip 0.2w/pcs 4000pcs/reelUS$ 0.0736 - 0.0752MOQ: 1 Piece
-
395-400nm UV SMD LED 2835NegotiableMOQ: 10 Pieces
-
3W Ceramic Infrared Laser 808nm High-Power Lamp Bead Night Vision Supplementary Light VCSELNegotiableMOQ: 1 Roll
-
Factory 5050 3535 4020 Chip Led Light Chip 5Mm 8Mm 10Mm Wide Bridgelux 12V 10W Led Chip Led Flood Light Chipp 5050 Rgb Led Diode 3D Light Diode ChipsLed 4 In 1 RgbwUS$ 0.053 - 0.054MOQ: 1000 Pieces
-
0.2W Digital Sk6812/LC8812C RGBW 4 In1 Addressable 5050 Smd ChipsUS$ 0.062 - 0.065MOQ: 1000 Pieces
-
SMD 0603 Series LedNegotiableMOQ: 4000 Pieces
-
150080RS75000 Wurth Elektronik Standard LEDs - SMD WL-SMCW SMDMono TpVw Waterclr 0805 RedUS$ 0.13 - 0.18MOQ: 10 Pieces
-
3W White Light High Powe LedHigh Power Pure White 1 Watt LEDUS$ 3.45 - 129MOQ: 5000 Pairs
-
5050RGB Colourful Lights-yingyueNegotiableMOQ: 500 Pieces
