Gearbox for Engraving Machine
- Shanghai
- T/T
You May Like
Product Details
| Gearing Arrangement | Planetary | Output Torque | 20N.m | |
| Input Speed | 2000Max | Output Speed | 20N.m | |
| Place of Origin | Anhui, China | Model Number | PM-70-CF | |
| Brand Name | BOLIN |
Product Description
Our company has great strength in R&D of planetary speed reducer, our technology partner is Hefei Industry University. We have many advanced testers such as service life tester, mechanical efficiency tester, noise measurement system to guarantee the quality.
The Planetary Gearbox above is special for engraving machine, with high precision, good steel proeprty, big load, high efficiency, speed ratio avaiable for many specifications, long service life, small inertia, and easy assembling for customers.
Welcome to visit our new factory at your convenient time!
| Technical parameters for planetary gearbox for engraving machine | ||
| No | Item | Parameter |
| 1 | Drive series | 1 phase |
| 2 | Total length | 150mm |
| 3 | Motor shaft length | 42, 52mm |
| 4 | Speed ratio | 4, 5, 7.5 |
| 5 | Rating output torque | 20 N.m |
| 6 | Backlash | 15arcmin |
| 7 | Input speed | 2000RPM Max |
| 8 | Axial load | 1500N |
| 9 | Radila load | 3000N |
| 10 | Working temperature | -20°C~+80°C |
