Specifications
Independent research and development capacityHigh speed,Operated easily
Warranty times: 12 months
CE certificate
Aluminum Foil Food Container Making Machine
Aluminum foil container making machine composed of the followings
1. Auto Feeder (with an auto-lubricator)
2. Electrical control panel
3. Air output control equipment
4. 45 ton pneumatic press
5. Mould
6. Auto-stacker or conveyor(including scrap collector)
7. Collection desk
Production Steps:
Feeding material
Punching by the press
Collecting product by the stacker
Collecting scrap by the scrap collector
Description of aluminum foil contaner making machine:
1. This production line can work automatically. Worker control and regulate this production line through electric control equipment.Feeding,punching,product & scrap collecting automatically.
2. Very reliable and steady as the controlling ststem complete with Siemens CPU 224 programmable logic controller (PLC)
3. It's integration of Gas & Electrical,centralized control.So feeding length,speed and other parameters are easy to set.
4. We can design and manufacture different machines on request.
5. Feeding is controlled by stepper syatem, the feeding length is accurate and can be adjusted from 20mm to 90mm.
6. Steel plate wielded machine body marked with high rigidity and less deformation
7. It adopts combined pneumatic friction clutch and barking device to ensure steady clutching, low noise level, and flexible action
8. Integrated lubrication system enables easy oil supply and smooth operation of the machine tool. The automatic lubricating system with fixed place, time and quantity is available to choose.
9. Photo-electric protection and automatic feeding device, driving output shaft and air cushion are available to choose
Aluminum Foil Rewinding Machine:
| XWSL-40 | XWSL-55 | XWSL-70 | XWSL-80 | |
| Max width of Roll | 350MM | 500MM | 650MM | 750MM |
| Max Unwind Roll Diameter | 600MM | 600MM | 600MM | 600MM |
| Feeding Speed | 0-35 | 0-35 | 0-35 | 0-35 |
| Feeding Length | 20-999 | 20-999 | 20-999 | 20-999 |
| Feeding Accuracy | ±0.3 | ±0.3 | ±0.3 | ±0.3 |
| Working Vollage | 380/220 | 380/220 | 380/220 | 380/220 |
| Total Power | 1 | 1 | 1.4 | 1.4 |
| Weight of Machine | 700 | 850 | 1000 | 1150 |
| Diemension | 2000*1150*900 | 2000*1300*900 | 2000*1450*900 | 2000*1550*900 |
High Accracy Press
| JF21-25 | JF21-45 | JF21-63 | JF21-80 | JF21-110 | |
| Nominal Pressure (KN) | 250 | 400 | 630 | 800 | 1100 |
| Slide Block Stroke(mm) | 80-160mm | 100-260mm | 120-260mm | 140-260mm | 150-260mm |
| Slide Strock Per Minutes(min) | 90-60 | 70-50 | 70-50 | 60-45 | 50-40 |
| Max Die Set Height(mm) | 250-300 | 270-400 | 310-450 | 325-450 | 345-500 |
| Die Set Height Adjustment(mm) | 50 | 60 | 70 | 80 | 90 |
| Slide Bottom Size(MM) | 330*250 | 410*340 | 480*400 | 560*460 | 630*520 |
| Stemhole Size(MM) | 60*60 | 60*60 | 60*65 | 60*75 | 60*85 |
| Bolster Surface Size(MM) | 700*320/800*480 | 810*440/990*750 | 870*520/1000*800 | 1000*600/1200*800 | 1100*680/1300*800 |
| Total Power(KW) | 3-4 | 5.5 | 5.5-7.5 | 7.5-11 | 11-15 |
| Weight | 2800-3100 | 3800-4500 | 5500-6300 | 8000-9000 | 11000-12000 |
Details of The Machine:
respective usage and functions:
(1) Airline aluminum foil tray
(2) coating food container
(3) Household aluminum foil
(4) Convenient carry-out aluminum foil container
(5) Turkey dish
(6) Other foil container,plate,pan,box,and tray
(7) egg tart ,cake plates
photo of the products:
our factory:
FAQ
Q:How could I get price from you?
A: Send us the details like shape;sizes; weight. Our sales team shall forward you the prices within 12 hours.
Q: I am new to the market, how do I know that if the quality and prices are good from Fresh Life?
A: Fresh Life's core compertance is "Insist on quality" Hence, for foil items; all prices are regarding on its weight.
Q: What would be the production lead time?
A: On average of 25-30days after receiving bond.
Q: What would be the payment terms?
A: 30% TT in advance as a bond; rest of 70% against documents.
