Home > Packaging & Printing > Printing Machinery > Screen Printer > Automatic Flat Silk Screen Printing Machine

Automatic Flat Silk Screen Printing Machine

Name: Automatic Flat Silk Screen Printing Machine
Brand: LAVY
SKU: 109683835
Availability: InStock

Automatic Flat Silk Screen Printing Machine thumbnail-1

Automatic Flat Silk Screen Printing Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Guangdong, China

Brand Name:

LAVY

Contact Supplier Request Quote Chat Now

Shantou Lavy Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shantou Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Guangdong, China

Brand Name LAVY

Model Number LV-500P

Usage Card Printer, Cloths Printer, Label Printer, Paper Printer

Automatic Grade Semi-Automatic

Voltage 110V / 220V

Gross Power 50W

Dimensions(L*W*H) 800x1000x1500mm

Weight 63Kg

Certification CE Certification

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Welcome to Lavy

We have over 10 years of experience in production, standard and customized machines for your products, please click contact us.

View more models

Application

Widely use on flat products, include Plastic,Metal,Ceramic,Paper etc material products.

Product Description

1.Each function is controled by Microprocessor to have high automation and easy operation.

2. Equipped LED digital counter

3.Printing available on curve, cylindrical and conical surface.

4.Both printing stroke and speed are adjustable to meet different printing requirements.

5.Squeegee/flood bar depth, pressure,speed,stroke and screen frame are all adjustable for various printing needs.

6.Auto balanced scraper ensures even pressuer.

7.Reliable control system and FESTO pneumatic components.8.A set of extra mould will be send with the machine for free.

Tech-Parameter

Electric screen printer
Model	LV-D500P	LV-D700P	LV-D6090P	LV-D80220
Worktable size	400×600mm	500×700mm	700×1100mm	1000×2440mm
Max.printing area	350×480mm	450×600mm	600×900mm	850×2200mm
Max. printing speed	1000pcs/hr	1000pcs/hr	800pcs/hr	800pcs/hr
Air consumption	104litre/min(6bar)	104litre/min(6bar)	104litre/min(6bar)	104litre/min(6bar)
Voltage	220V 60/50Hz 0.75Kw	220V 60/50Hz 1.5Kw	220/380V 60/50Hz 3.5Kw	110/220V 60/50Hz 4Kw
Dimensions(L×W×H)	800×1000×1500mm	970×1160×1760mm	1200×1000×1650mm	1600×2800×1800mm
Net Weight	160Kg	240Kg	600Kg	750Kg

Warranty

1 Year after customer receive the machine

FAQ

Q: I am the new hand for the creen printer,can you show me how to operate?

A: Certainly. There are many customers to buy the machine the first time.

1- We will send the testing videos for your reference. Most of the customers can operate the machine by following the videos.

2- The notes during operate the machine will be offered.

3- If there is any problem, you can contact with us any time, we will answer in 24 hours

4- For the big machine with complex testing and operation, engineer is available for the overseas service

Q: Do you offer free charge of the designs?

A: If you purchase the other screen accessories from our company, we will offer free charge of the artwork according to your information.

Q: Can I put some designs into one screen plate?

A: Yes, on this way the first design is free charge. From the second designs, if the design is the same, only with different sizes, we will not charge for the designs. But we do not suggest the new hand to put many designs onto one plate, the operation will be affected.

Q: How can I offer the designs?

A: Please offer the file with CDR, AI, PSD, PDF, DOC, JPG, or DWG format.

Q: Do you also supply inks, UV dryer,Screen Printing Exposure Unit Vacuum machine

A: Yes, we offer the accessories with good price.

Q: How do I pay for my order?

A: We accept T/T,Western Union,MoneyGram. Paypal is acceptable for less than $1000.
