Help CenterN-5 Switch Box
US$ 3 - 18
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
cansen
Model Number:
LW26
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rotary Switch LW26 (CE Certificate)US$ 2 - 18MOQ: 10000 Pieces -
Power Switch LW26GS-100 (ROHS,CE Certificate)US$ 2 - 20MOQ: 100 Pieces
-
Remote Switch LW26-32F(CE Certificate)US$ 2 - 18MOQ: 100 Pieces
-
Main Key Switch LW26S2-32US$ 2 - 18MOQ: 100 Pieces
-
Rotary Cam SwitchLW26S-10 (CE Certificate)US$ 2 - 18MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
cansen
Model Number
LW26
Max. Current
20
Max. Voltage
660
Mechanical Life
100000
Specifications
productive history for 30 years,current range:20A
certificate:CE
switch box
No. |
Tech Parameters |
requirement |
1. |
rated voltage |
below 690V |
2. |
rated current |
20A |
3. |
frequency |
AC50HZ |
4. |
No.of poles |
|
5. |
No.of layers |
3 layers |
6. |
panel size |
48*64mm |
7. |
colour of handle |
black, |
8. |
Working temperature |
-25°C~+40°C REMARKS:the average temperature mustn’t be pass 35°C |
9. |
Working height |
≤2,000m |
10. |
Relative humidity |
≤50% with highest temperature +40°C,but allow higher humidity with low temperature less than 40°C (eg.:humidity 90%----teperature20°C) |
11. |
Instalation conditions |
polution class III |
12. |
Mechanical life |
0.1*106times |
13. |
Electrical life |
0.03*106times |
14. |
Operative frequency |
120times/hour |
15. |
transform angle |
45° |
