MIC48-36-8 wine filling machine

MIC-- Automatic glass bottle beverage/wine filling machine 3 in 1

1)Bottle clip with double clamp mechanism, upper clip grip mouth of bottle, lower clip grip bottle, two clips clamped bottle simultaneously. When bottle moving at high speed, this architecture facilitates help to avoid injury due to the centrifugal force of the bottle itself (single clip mechanism easier to put the bottle thrown out) the bottle out from bottle clips.

2) Rinse bottle parts: Rinsing machine have reasonable structure, convenient adjustment, adapt to a wide range, Lubrication complete in place, beautiful shape, all the materials used to meet the food hygiene requirement.

3)Diverter plate hose fittings with imported fast-plug connectors. Diverter plate with wear-resistant waterproof material POM, sealed with silicone materials, wear-resistant, resistant to ozone. Washing area have plexi glass shields against bottle water spill.

4) Clip bottle head: bracket and flip section and other components are made of 304 stainless steel with multiple processes from CNC machining. Bottle holder is stainless steel, not easy to pollute, easy to washing, durable, yield not less than 15,000 bottles/hour.

5) Center water inlet pipe using methods as picture: not the kind of tee welding, welding can cause breakage.

6) Isobaric filling machine: the overall structure of filling machine are advanced, simple, reasonable. Its transmission and lifting gear place on rack, below stainless steel table, waterproof performance, reliable sanitation, easy to adjustment and maintenance. Filling machine lifting guide pillar place kits, have lubrication points, to ensure long-term adjustment and flexible.

Filling valve and other parts are made of STS304 stainless steel finishing, with a guide ring to avoid metal friction . Using Han Sheng sealing elements of Taiwan, good sealing performance. Speed of filling valve is fast, flow 80ml / s, exhaust fast, accurate.

7) Inflatable pressure: After the bottle and the valve seal, open the valve mechanism toggle plate machine, open the upper gas valve of filling valve, make the gas in filling cylinders to fill the bottles quickly, achieve a filling cylinder pressure and bottle pressure equal.

Filling return air: After constant pressure to achieve, filling the spool rely on springs open automatically, liquid flow automatically down by fluid pressure differential along sidewall of bottles, watershed ring let liquid become some shape like umbrella .

8) At the same time, the inner air of bottles return filling cylinders through back to the trachea . When the liquid level rises to the lower mouth of back to the trachea, gas can not be returned to filling cylinders, pressure will rise at the bottleneck of empty place. Then cylinder liquid poured into the bottle can not continue.

9) Close the valve, release pressure: After filling is completed, the filling valve is closed under the action of closed valve mechanism , Then, under the control of the pressure-release plate, exhaust piston is opened, the inner air pressure to slowly discharge, similar to the outside atmospheric pressure to prevent the bottle from the valve port to generate foam overflow phenomena.

10) Washing, filling and capping equipment are free to adjust the height within the range specified in order to use different height bottles. When the diameter of the bottle in a predetermined range, a constant diameter of the bottle, the bottle height has changed, only need to adjust the height of the relevant parts of each device without replacing parts.

If the diameter of the bottle changes need to replace screw feeder, drive plate and guide plate.

We have doing wine filling machines for 8 years, after the company recombination, the wine filling machine we sold to Europe, Africa, the America states and south America. We can guarantee our filling machine line for years running with steady working.

We provide 8 hour action, 24hours solution after sale service, in order to avoid the time difference bring the economic and trust lost to our clients.

Wine filling machine is packed with export wooden case.

We will offer our technician for oversea wine filling machine installation and training service.

we can also provide our Sales as translator to your site help the installation and Training. Only to provide the local transportation, accommodation, air tickets (round trip) for Sales will be fine.

Thank you for choosing MIC Machinery Company.

For Wine filling machine question:

First of all, before we operate wine filling machine , to clearly understand the instructions clearly  wine filling machine , first read through the instructions again, adjust and use the familiar  wine filling machine , the operating time must be in strict accordance with the instructions to wine filling machine instructions , pay attention to details of the problem , certainly the details determine success or failure .

Secondly , in accordance with the instructions on the machine for regular repair and maintenance of the wine filling machine fuselage Oil it , so wine filling machine body as far as possible to protect the reservoir , so that the air can be isolated to avoid wine filling machine rusty , well protected wine filling machine body, and this is a way to extend the life of the 3 in1 filling machine .

Once again, we have to pay attention to hot stand -sealing cloth for cleaning, not retained foreign body in the above , to ensure clean  wine filling machine try to avoid the amount of material for a long time into the mouth of the left cause corrosion .

Fourth, we should always check the machine to see contacts at various parts of the machine is good, important to ensure safe use of electricity , no electricity properly to prevent harm .

Fifth, if found faulty , we have to turn off the power , when necessary, by pressing the emergency stop button , and then deflated lift cover, and then close the voltage , check the reason , and troubleshooting.

Detail picture of wine filling machine:

Sealling parts of wine filling machine:
