Home > Electrical & Electronics > Switch > Rotary Switch > It Can Replace KG20 Kraus&Naimer Switch LW30-100ROHS,CE Certificate)with Protective Cover
It Can Replace KG20 Kraus&Naimer Switch LW30-100ROHS,CE Certificate)with Protective Cover
US$ 2 - 22
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
cansen
Model Number:
LW30
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
It Can Replace the New Kraus&Naimer Switch LW30-100ROHS,CE Certificate) With Protective CoverUS$ 2 - 22MOQ: 100 Pieces -
It Can Replace KG41 Kraus&Naimer Switch LW30-100ROHS,CE Certificate)with Protective CoverUS$ 2 - 22MOQ: 100 Pieces
-
Waterproof Switch LW30-100ROHS,CE Certificate) With Protective CoverUS$ 2 - 22MOQ: 100 Pieces
-
Load Switch LW30-100 With ROHS CE CertificateUS$ 2 - 22MOQ: 100 Pieces
-
Cansen New Switch LW30-100ROHS,CE Certificate)with Protective CoverUS$ 2 - 22MOQ: 100 Pieces
Place of Origin
China
Brand Name
cansen
Model Number
LW30
Max. Current
100
Max. Voltage
660
Mechanical Life
100000
Specifications
productive history for 30 years, current range:20A to 100A certificate:Rohs&CE IP class:IP65It can replace KG20 Kraus&Naimer
No. |
Tech Parameters |
requirement |
1. |
rated voltage |
below 440V |
2. |
rated current |
20A,25A,32A,63A,80A,100A |
3. |
frequency |
AC50HZ |
4. |
No.of poles |
2P,3P,4P |
5. |
No.of layers |
make as required with circuit diagram |
6. |
panel size |
64*64mm |
7. |
colour of handle |
black,white,red,grey |
8. |
Working temperature |
-25°C~+40°C REMARKS:the average temperature mustn’t be pass 35°C |
9. |
Working height |
≤2,000m |
10. |
Relative humidity |
≤50% with highest temperature +40°C,but allow higher humidity with low temperature less than 40°C (eg.:humidity 90%----teperature20°C) |
11. |
Instalation conditions |
polution class III |
12. |
Mechanical life |
0.1*106times |
13. |
Electrical life |
0.03*106times |
14. |
Operative frequency |
120times/hour |
15. |
transform angle |
90° |
