Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Packaging Equipment > PGL-C Series Spray Dryer Granulator
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Etage
Model Number:
PGL-C
Payment & Shipping
Payment Methods:
Port of Shipment:
chongqing port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Chongqing, China
Brand Name
Etage
Model Number
PGL-C
Usage
Capsule
Production Capacity
2-450Kg/bstch
Specifications
combines spraying,dring,mixing and granulation into one.makes granules with fews assistan materials,small dosageamount.
It is a new type of granulation spray drying and fluid bed machine combining technique of granulation.It utilizes negative pressure hot air flow to dry the liquid in spray chamber and the
liquid on materials very fast ,and also agglutinate them together into granules.The size of granules can be controlled by adjusting parameter.
Combines spraying, drying, mixing and granulation into one. Makes granules with few assistant materials, small dosage mount, low sugar or sugar free. Granules dissolved insatntly, drinking preparation easily dissolve out and tablets disintegrated easily. Machine works at negative pressure with smooth and cleaning inside surface without dead corners.
| Item | unit | PGL-3C | PGL-5C | PGL-10C | PGL-20C | PGL-40C | PGL-80C | PGL-120C |
| Capacity | kg/batch | 2-5 | 3-15 | 10-30 | 30-80 | 50-160 | 100-250 | 150-450 |
| Capacity for extracsity | kg/batch | 1-4 | 2-8 | 4-20 | 8-40 | 20-60 | 40-120 | 100-140 |
| Liquid gravity | kg/L | <=1.3 | <=1.3 | <=1.3 | <=1.3 | <=1.3 | <=1.3 | <=1.3 |
| Volume of fluid bed | L | 26 | 50 | 120 | 300 | 500 | 750 | 1100 |
| Main Fan Power | KW | 3/4 | 4/5.5 | 7.5/11 | 11/15 | 18.5/22 | 30/37 | 45/55 |
| Assistant Fan power | KW | 0.55 | 0.55 | 1.10 | 1.10 | 1.5 | 1.5 | 2.2 |
| Steam Consumption | Kg/Hr | 40 | 70 | 99 | 210 | 300 | 420 | 530 |
| Steam Pressure | Mpa | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Power of electric heating | KW | 9 | 15 | 21 | 25.5 | 51.5 | 60 | 75 |
| Compresed air consumption | Cubic meter/min. | 0.5 | 0.8 | 0.8 | 09 | 1.1 | 1.3 | 1.8 |
| Compressed air pressure | Mpa | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Mositure | % | >2% | >2% | >2% | >2% | >2% | >2% | >2% |
| Working Temperature | Degree | Normal-120 degrees | Normal-120 degrees | Normal-120 degrees | Normal-120 degrees | Normal-120 degrees | Normal-120 degrees | Normal-120 degrees |
| Gain ratio | % | >=95% | >=95% | >=95% | >=95% | >=95% | >=95% | >=95% |
| Noise | DB | <70 | <70 | <70 | <70 | <70 | <70 | <70 |
| Dimension | cm | 219*72*72 | 265*98*98 | 305*113*113 | 353*143*143 | 402*163*163 | 450*183*183 | 543*203*203 |
