Pdc Drill Bit Drill Bit Oil Drill Bit High Quality Mud Agitator
- TianJin
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Brightway | |
| Model Number | BWJBQ5.5 | Certification | API |
as customer required
Product Description
Specifications
1,high efficiency mud agitator2,good quanlity mud agitator
3,two year guarantee
3, can be customized
Discription
Mud Agitator is widely used in the mud solids control system.Mud Agitator is used in mud systems to suspend solids and maintain homogeneous mixture throughout the system. A mechanical agitator is driven by an explosion-proof motor, coupled to a gear box that drives the impeller shaft. The impellers (turbines) transform mechanical power into fluid circulation or agitation. The objective is to obtain a uniform suspension of all solids. Brightway mud agitator features a “C” face motor couple to a rugged oilfield gearbox, which eliminates misalignment and troublesome couplings. This configuration promotes long motor and gearbox bearing life. Please contact with Brightway representative with your tank dimension and your detail requirement. We will recommend the right model with specification about the horsepower, impeller (size, type& quality), and shaft length etc to meet your requirement.
Brightway Mud Agitator Features and Benefits
1. Structure: Small footprint and compact structure.
2. Reduction gearbox: Helical-bevel design or worm design according to customer requirement.
3. Motor: Explosion-proof electrical motor, and can be the style of horizontal or vertical.
4. Shaft and impeller: Galvanizing treatment brings the excellent anti-rust performance much better than the painting process
5. High efficiency, low noise, low operating temperature.
Model | BWJBQ5.5 | BWJBQ7.5 | BWJBQ11 | BWJBQ15 |
Power | 5.5Kw | 7.5Kw | 11Kw | 15Kw |
Impeller Speed | 60/72RPM | |||
Impeller Dia | 600mm | 750/850mm | 750/850mm | 750/850mm |
Ration | 25:01:00 | |||
Dimension | 870×600×560mm | 906×600×560mm | 1075×650×630mm | 1170×720×685mm |
Electric specs | 380V/50Hz or 460V/60Hz | |||
Shaft Length | According to tank inside depth | |||
Remark | Explosion Proof Motor | |||
Company Profile
Xi'an Brightway Energy Machinery Equipment Co., Ltd. is specialized in the manufacture of the mud solids control equipments and the complete set of solids control system. We focus on: 1) Oil and gas drilling mud system 2) HDD drilling mud recycling systems 3) CBM drilling mud cleaning systems 4) Underground engineering systems 5) Geothermal well engineering systems 6) Environment & waste mud treating systems Brightway mud solids control equipments: Shale shaker, vacuum degasser, mud cleaner, desander cleaner, desilter cleaner, decanting centrifuge, sand pump, submersible slurry pump, mud agitators, self-suction sand pump, jet mud mixer, mud gas separator, mud gun, screw pump, shear pump, flare ignition device, oil tank, water tank, and mud tank, etc.
