12kV Outdoor Vacuum Switches / VCB
US$ 1,695 - 2,000
MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Shuguang Electric
Model Number:
ZW32-12
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pole Mounted Outdoor Vacuum Circuit BreakerNegotiableMOQ: 3 Sets -
12kV Indoor Circuit Breaker Disconnecting SwitchNegotiableMOQ: 3 Sets
-
3AV3 Spring Operating MechanismNegotiableMOQ: 1 Piece
-
CT100 Spring Operating MechanismNegotiableMOQ: 1 Piece
-
12kV Indoor Circuit Breaker Disconnecting SwitchNegotiableMOQ: 1
Place of Origin
Zhejiang, China
Brand Name
Shuguang Electric
Model Number
ZW32-12
Type
Vacuum
Poles Number
3
Specifications
Vacuum switches:1.Good quality and competitive price
mpt delivery,small order accepted
3.Certificate:Type Test
ZW32-12 series pillar type outdoor vacuum breaker is a kind of outdoor H.V switch equipment with 50Hz three-phase alternating current and rated voltage 12kV. It apply tobreak and close the load current and short-circuit in cities or country power distribution system.
- Rated voltage: 12kV
- Rated frequency: 50Hz
- Rated current: 630 A
- Power frequency withstand voltage (1 min):
- Dry test: 42kV
- Wet test: 34kV
- Rated short-circuit breaking current: 20 kA
- Duration of rated short-circuit: 4s
- Breaking times of rated short-circuit breaking current: 30 times
- Rated short-time withstand current: 20kA
- Rated short-circuit making current: 50kA
- Rated peak withstand current: 50kA
- Rated operating sequence: O-0.3s-CO-180s-CO
- Mechanical endurance: 10,000 times
- Rated lighting impulse withstand voltage: 75kV
- Storage duration under rated voltage: ≤8s
- Voltage of operating mechanism and closing/opening electromagnet: 220-110V/48-24V
- Breaking time: 3s
- Weight: 85kg
