CT Bushing Insulator
TGZ35-12
Size: 778*150mm
Mounting Hole Distance: 108mm 4-M8 x 1.25-6H Mild Steel
CT Insert Size: Φ70mm
Conductor Size: Φ38mm * 598mm
Rated Voltage: 12 KV
Partial Discharge: 9.1KV Less Than 5 PC & 13.0KV Less Than 10 PC
Short Time Current: 31.5KA 3Sec
Temperature Classfication: -5 Centigrade Degree Indoor
Rated Current: 1250A
Power Frequency Withstand Voltage: 28 KV
Impulse Withstand Voltage: 95KV
Creepage Distance: Min. 20mm/KV
Material:Cast Epoxy CW229/HW229
Conductor:HDHC Cu.C101
Finish: Zinc Arc Spray, Stress Grade Varnish,
Company Information:
Established Date: the Year of 1991
Total Investment: USD 26 Million
Land Area: 50,000 square meters
Annual Production Capability: USD 80 Million
Strict Quality Control & Good After Sale Service
Selective epoxy resin & firm agent
Strictly add active silica powder to epoxy resin to strengthen the insulator's work performance
Strict and formulated production & process to ensure maximum of mechanical properties
