Help Center3150A Bushing Insulator
Negotiable
MOQ: 3 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Shuguang Electric
Model Number:
CHZ10-308
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
12kV Composite Polymer Insulator BushingNegotiableMOQ: 3 Pieces -
24kV Epoxy Resin Switchgear Contact BoxUS$ 15 - 20MOQ: 100 Pieces
-
24kV Epoxy Resin Switchgear Contact BoxUS$ 15 - 25MOQ: 10 Pieces
-
24kV Isolation Contact Spout BushingUS$ 30 - 40MOQ: 10 Pieces
-
10kV Isolation Contact Spout BushingNegotiableMOQ: 1
Place of Origin
Zhejiang, China
Brand Name
Shuguang Electric
Model Number
CHZ10-308
Type
Insulator
Material
Other, Epoxy Resin
Application
High Voltage
Rated Voltage
12kV
Tensile Strength
10KN
Specifications
1.Epoxy resin cast insulators2.Certificate Standard:Test Report
3.Good quality and competitive price
4.ISO9001:2008,ISO1400
General Description
1.The Contact Box is formed by epoxy with APG technolgy, it is used for insulation isolation and connection for ansition of various switch trucks;
2.Altitude:≤1000m;
3.Ambient temperature:+40°C~10°C;
4. NO gas ,wapor or dust that may severely affect the insulation of contact box,no explosive or corrosive substance.
Technical Date &Requirement
1.The coper contact to earth shall withstand power frequency test voltage(effective value )of 42kv for 5 minutes and lightning impulse vpltage (peak value)of 75KV;
2.The temperature of lead-out terminal shall not bemore than 65°C if the contact box is used for long time in rated
current condition
3.See the attached figure for the outline and installation dimension of contact box.
