Specifications
FOR FORD OEM NAVIGATION RADIO TV IPOD 3G1)AM,FM,DVR,IPOD,TV,BT,Phonebook,GPS
2)6 CDC virtua
3)3G
4)CE&RoHS
FOR FORD OEM NAVIGATION RADIO TV IPOD 3G
Item Model No.: JWD-1504M
Car Model fitting:
ford focus(2005-2007)/c-max(2006-2010)fiesta(2005-2008)/fusion(2005-2009)/galsxy(2000-2009)/transit(2006-2011)/kuga
-----------------------------------------------------------------------------------------------------------------------
Brife introduction:
- GPS wince6.0 system,dual zone
- Build-in Bluetooth for hand free,serching name, phonebook with caller ID display
- 6 CDC virtua
- car paking system automatically switching when reversing
- 3G interface,support 3G
-----------------------------------------------------------------------------------------------------------------------
Descriptions:
| GPS | |
| Operating System | Windows CE 6.0 ARM11 Platform SIRFatlas IV A4 500MHz ARM11 + 250MHz DSP 128MB DDR |
| GPS Resolution Output | 800x480 |
| Media Player | Yes |
| Card Supported | Micro SD card |
| MAX Memory Supported | 16 GB |
| Map Supported | PolNav, Igo, Route66, Tom-Tom, Support 3D Maps |
| GPS Baud Rate=9600, Com Port=2 | |
| Display Screen | |
| Screen Type | Digital TFT touchscreen |
| Resolution | 800*480 |
| Screen Dimension | 7 inch 16:9 |
| Language | |
| Main Interface Language | English,Francais,Deutsch, italian,Espanol,Russia,Germany |
| DVD Control Language | English, Francais, Spanish |
| GPS Console Language | English, Franch,Portugues,Spanish,Italian,Germany,Russia |
| DVD Playback | |
| Disk Format Supported | DVD/VCD/CD/MP3/MPEG4/CD-R/WMA/JPEG |
| Media | DVD/DVD-R/DVD+R/DVD-RW/DVD+RW/CD/CD-R/CD-RW/MP3/MP4(DIVX)/VCD/SVCD |
| Bluetooth | |
| A2DP | Yes |
| Microphone | Built-in+External |
| Received Call | Yes |
| Dialled Call | Yes |
| Missed Call | Yes |
| Download Contacts | YES |
| Store Contacts | YES |
| TV Tuner | |
| Built-in Analog TV | Yes |
| Analog TV System | NTSC, PAL-B/G, PAL-I, PAL-D/K,PAL-M,PAL-N,SECAM-BG,SECAM-DK |
| Built-in DVB-T Tuner | Optional |
| DVB-T Format | / |
| Built-in ISDB Tuner | Optional |
| Radio | |
| AM Frequency Range | 522-1620 (Europe), 530-1710 (America),522-1620 (Russia), |
| FM Tuning Range | 87.5-108 (Europe), 87.5-107.9 (America) |
| RDS | Yes |
| iPod Control | |
| Touchscreen Control | Can Control Music Through Touchscreen |
| Show Information Of Music | NO |
| Play Video | NO |
| Storage Media | |
| SD Card Slot For Music/Movie | Micro SD card Slot |
| MAX Memory Supported 16GB | |
| USB Port For Music/Movie | Normal USB Port |
| MAX Memory Supported 16GB | |
| Position: USB port located in front panel and back of unit | |
| Portable HD | No |
| Video & Audio | |
| Video Input | 1-Channel RCA Input |
| Video Output | 2-Channel RCA Output |
| Audio Input | 2-Channel RCA Input |
| Audio Output | 4.1-Channel RCA Output |
| Reverse Camera Input | Yes |
| 3 Zone Out | No |
| Other Functions | |
| 2-Zone | Yes (Listen Radio/CD While Watching GPS Image) |
| 3-Zone | No (Listening To Radio/Watching GPS Image At The Front And Watching DVD/SD/USB/TV From The Sub-monitor Simultaneously) |
| Pictrue In Pictrue | No |
| Steering Wheel Control Function | Yes |
| CANBUS | No |
| MFD | Yes |
| TMC | Optional |
| V-6 Disc Changer Memory | No |
| CDC | NO |
| Parking Assistance | no |
| Game | Yes |
| Button Back Light | Orange Illumination |
| Accessories | |
| User Manual*1,Power Cable*1,Remote Control*1,iPod Control Wire*1,GPS Antenna*1 | |
-
DVD Player:
GPS:
IPOD:
6 CDC virtua:
* It support 6 disc copied in memory.
* In the state of playing music , it can copy whole discs.
Only 10 minutes, you can make-----------------------------------------------------------------------------------------------------------------------
Optional Function:
1)DVB-T / ISDB-T/ ATSC
2)External Microphone
3)SD Card with map
4)OEM Rear View Camera
5)canbus box
----------------------------------------------------------------------------------------------------------------------
Accessories in the package:
1 × Multimedia DVD Player
1 x External Microphone
1 × English User Manual
1 × Remote Controller
1 × Power Cable
1 × USB wire
1 × IPOD wire
1 × GPS antenna
-----------------------------------------------------------------------------------------------------------------------
Packaging & Shipping
Packing details:
Gross Weight: 5kg
Net Weight: 4.5kg-----------------------------------------------------------------------------------------------------------------------
