7 inch industrial panel pc,all one pc,all in one touch screen

Name: 7 inch industrial panel pc,all one pc,all in one touch screen
Brand: Jwell
Availability: InStock

FOB Price

USD $430 - $530 / Set

50 Sets(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port SHENZHEN
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Type	All-In-One
Screen Size	Other, 7 inch	Processor Brand	Intel
Memory Capacity	Other, ≥ 4GB	Hard Drive Capacity	500GB
Graphics Card Type	Integrated Card	Display Type	LCD
Widescreen	No	Optical Drive Type	Other
Processor Main Frequency	D525 1.8GHz dual core	Brand Name	Jwell
Model Number	JW-788PC	Place of Origin	Guangdong, China

Product Description

Specifications

7 inch all in one touch screen
1.OEM available
2.CE FCC RoHS
3.18 months warranty

Product Description

Quick Details

Products Status: Stock
Type: All-In-One
Screen Size: 7"
Processor Brand: Intel
Memory Capacity: 4G
Hard Drive Capacity: 500GB
Graphics Card Type: Integrated Card
Display Type: LCD
Widescreen: No
Processor Main Frequency: D525 1.8GHz dual core
Brand Name: JWELL
Model Number: JW-788PC
Place of Origin: Guangdong, China (Mainland)
Screen size: 7"
Resolution: 1280X800 ( 1920 x 1200 optional )
Brightness: 400cd/m2
Contrast: 700:1
Built-in W-Lan Antenna: 802.11b/g/n ( optioal )
Independent graphics: NVIDIA ION2
Photo quality: Support 1080P
View angle: Full view angle
Color: Black, Silver

Packaging & Delivery

Packaging Details:	1pc/ctn
Delivery Detail:	3days

Specifications

7 inch china all in one pc wholesaler
1280*800/1920*1200 700:1 400cd/m2
Inter D525 Dual core NVIDIA ION2 1080P

7 inch all in one touch screen

Iron/Aluminum All In One PC with LCD screen

Super slim Tablet fashion design

High quality industrial grade

Support DVI/VGA,HDMI,S/PDIF,double-channel LVDS interface,

Double-groove DDR3 memory

Maximum memory capacity support 4GB

Model:	JW-788PC
Name:	7 Inch Fanless Ultra slim all-in-one open frame touch pc
Description	Fanless Ultra slim Panel PC
Monitor size	7" LED 4:3
Touch typ	4 –wires resistive touch
Surface hardness	3H
Transmittance	≥80%
Sensitive	< 10ms
Resolution	1280× 800 ( 1920X1200 optional )
Brightness	400cd/m2(Typ)
Contrast	700:1
LCD color	16.7M colors
Pixel Pitch	0.264 x 0.264
Life time	Single-point 10000,000 times , Draw lines 100,000 times
Operating temperature	-20°C~60°C
Storage temperature	-30°C~80°C
Working Humidity	5%—95%,40°C,Non –condensing
Vibration	5-100Hz,Sine wave,11.76m/S2,1minute X,Y,Z directions,10 times / direction
Shock	294m/S2 11ms ,half-sine wave,±X,±Y,±Z directions,3times /direction
SBC Model	ALL IN ONE special & professional SBC
CPU	On board Intel® Atom D525 1.8GHz dual core
BIOS	Award BIOS 4/8Mbit SPI Flash ROM
Chipset	Intel NM10 Express Chipset
Memory	2×204-pin DDR3 DIMM up to 4GB
Graphics	Independent Graphics NVIDIA ION2 and support 1080p HD photo quality
Audio Card	Realtek ALC662 high Definition audio codec
Network	2×Realtek RTL 8111E Gigabit Ethernet controller,(Wireless Wifi)
I/O	4×USB 2×COM 1×VGA/LAN/HDMI/Audio OUT/MIC IN/S/PDIF/POWER DC
Hardisk interface	2.5”SATA (SSD optional )
Watchdog	Support system reset grade 0~255
Power supply	DC 12V input
Operating temperature	-20°C~60°C
Storage temperature	-30°C~80°C
Working Humidity	5%—95%,40°C,Non –condensing
Vibration	5-100Hz,Sine wave,11.76m/S2,1minute X,Y,Z directions,10 times / direction
Shock	294m/S2 11ms ,half-sine wave,±X,±Y,±Z directions,3times /direction
Case	Metalcase , shockproof , anti-interference , metal shell(paint))
Installation ways	Rackmount , Embeded , wall mount ,VESA bracket
Shock	294m/S2 11ms ,half-sine wave,±X,±Y,±Z directions,3times /direction
Case	Metalcase , shockproof , anti-interference , metal shell(paint))
Installation ways	Rackmount , Embeded , wall mount ,VESA bracket

Features

a. Standard with Intel® Atom^TMDual-core processor.

b. High brightness ,Full view angle IPS TFT panel .

c. Multi-directional heat- releasing structure .

d Built-in W-Lan Antenna(802.11b/g/n) .

e. Ultra slim metal design , beautiful ,durable and rugged.

f. Independent graphics NVIDIA ION2 and support 1080p HD photo quality .

Connector port

1 X VGA

1 X HDMI

1 X Gigabit LAN

4 X USB

1 X Audio Out

1 X MIC IN

1 X S/PDIF

1 X COM

1 X POWER DC IN

Compatible Operating System

Windows XP Embedded

Windows CE

Linux

Optional Display size:

7 inch, 8inch, 9 inch, 10 inch, 12.1 inch, 15 inch, 17 inch, 22 inch

Simialr Models for touch screen monitor

Please click here to link in TOUCH SCREEN MONTOR

Our Services

1. Quick and accurate reply with best service attidue to our business

2. Pofessional advise

3. Quick PI confimation

4. Close production follow up and production process feedback

5. Safe package

6. Get feekback from your side when items arrived,

7. 12 months warranty for items

FAQ

Q: What kind of inspection you can provide?

A: JWELL has multiple tests from material purchasing to finished products by different departments, like QA, QC, sales representatives, to guarantee all foldable monitor are in perfect condition before shipment. We also accept the inspection by the third party you appointed.

Q: What is your guarantee period?

A: JWELL provides 12 months' quality guarantee for foldable monitor from your purchase date, except the human damaged and force majeure factor. For a better maintenance, be sure that foldable monitor are using under normal circumstances (not more than 16 hours daily). Beyond the guarantee period machine, JWELL will provide maintenance service and technical support (Hardware and other possible charges, JWELL will not bear the responsibility)

Q: How can I pay for the order?

A: Our payment terms: T/T, Western Union, Paypal, Escrow, Credit card

1) For sample order: 100% T/T or Western Union in advance, Paypal or Escrow is also acceptable.

2) For bulk order: 30%deposit T/T in advance, balance clear before pick up or shipment.
