Tachometer RZSM6234E

Tachometer RZSM6234E

Display: 5digital, 18mm LCD

Range: 2.5~99999 RPM

             0.05~1666 Hz

             1~99999 Count

Resolution: 0.1 RPM (2.5~999.9RPM)

                    1 RPM (above 1000RPM)

                    0.01Hz (0.05~99.99Hz)

                    0.1Hz (above 100Hz)

Accuracy: ± (0.05%+1digital)

Sampling Time: 0.8second (over 60RPM)

Memory: Max. value, Min. value, Last value. 96 data record.

Range Select: Auto-range

Time Base: 6MHz Quartz crystal

Detecting Distance: 50mm-500mm

Dimension: 155*70*35mm

Power: 3×1.5V AAA battery

Introduction:

This item is used the microcomputer (CPU) technique, photoelectric technology, anti-jamming technique and junction laser technique for non-contact measurement of Rotation speed (RPM), Frequency (Hz), and total cycle (Total)

Feature:

1-Model: RZSM6234E

2-Color: Blue & Black

3-Professional Photo tachometer

4-100% brand new

5-Wide measuring range and high accuracy.

6-Memory: Max value, Min value, Last value. Can store 96s data

7-LCD backlight to make sure that it can be used in any light circumstance.

8-Low battery indication

9-Smooth housing design, comfortable to be held.

Specification:

1-Measuring Range:
RPM: 2.5~99,999RPM
Hz:   0.05~1666Hz
Total: 1~99999 Count

2-Resolution:
RPM: 0.1RPM(2.5~999.9RPM);1RPM(over 1,000RPM)
Hz:   0.01Hz (0.05~99.99Hz); 0.1Hz (above 100Hz

3-Accuracy: ±(0.05%+1 digit)

4-Detecting Distance: 50~500mm

5-5 digits LCD display
6-Sampling Time: 0.8 sec (over 60RPM)
7-Time Base: 6MHz Quartz crystal
8-Battery: 3xAA 1.5V Battery

9-Weight: 120g

10-Dimension:155x70x35mm

1 x Photo tachometer

-Reflecting tape marks: length 600mm

1 x Operation manual

3 x 1.5V AAA batteries

1 x carry bag
