Network Gi wire mesh cable tray
HDMANN WIRE MESH CABLE TRAY SYSTEM
HDMANN wire mesh cable tray is constructed of precision engineered, high quality, welded steel wire and is the result of decades of research gained from the installation of 94,000 miles of tray across the globe.
Our wire mesh cable tray is subjected to testing at every stage of the manufacturing process. In actual use, it has performed in a wide variety of office buildings and is widely used for from heavy power cable pathways on oil drilling platforms to data installation above the ceiling.
Our wire mesh cable tray is alailable in depths of 25-150mm, and in a variaty of widths, ranging from 30-1000mm. The standard finish is electroplared zinc after fabrication. A variaty of other finishes available are including hot dipped galvanized after fabrication, pre-galvanized as well as multitude of colors in powder coating. The wire mesh cable tray is also available in type 304 and 306 stainless steels for extremely corrosive enviroments.
As for the wire mesh cable tray fittings, the fittings can be fabricated in field. However, to expedite installation, HDMANN offers factory assembled horizontal fittings. The pre-fabricated fittings are time-saving and cost-effective compared with the field-fabricated horizontal fittings, which enjoys a great reputation. A complement of accessories and brackets used for wire mesh installation are also provided. See our catalogue unpon request.
WIRE MESH CABLE TRAY TECHNICAL DATE:
| Table of standard wire mesh cable specifaction | |||
| H*W | Profile wire Nos | Wire dis(mm) | Weight(kg/meter) |
| 35*100 | 4 | 4 | 0.58 |
| 35*150 | 5 | 4 | 0.73 |
| 35*200 | 6 | 4 | 0.89 |
| 35*300 | 8 | 4 | 1.2 |
| 50*50 | 5 | 4 | 0.66 |
| 50*100 | 6 | 4 | 0.82 |
| 50*150 | 7 | 4 | 0.97 |
| 50*200 | 8 | 4 | 1.12 |
| 50*300 | 10 | 5 | 2.24 |
| 50*400 | 12 | 5 | 2.72 |
| 50*450 | 13 | 5 | 2.96 |
| 50*500 | 14 | 5 | 3.2 |
| 50*600 | 16 | 5 | 3.68 |
| 50*750 | 19 | 6 | 6.35 |
| 50*800 | 20 | 6 | 6.69 |
| 100*100 | 8 | 4 | 1.13 |
| 100*150 | 9 | 4 | 1.28 |
| 100*200 | 10 | 4 | 1.43 |
| 100*300 | 12 | 5 | 2.72 |
| 100*400 | 14 | 5 | 3.2 |
| 100*450 | 15 | 5 | 3.44 |
| 100*500 | 16 | 5 | 3.68 |
| 100*600 | 18 | 5 | 4.16 |
| 100*750 | 21 | 6 | 7.04 |
| 150*200 | 12 | 5 | 2.72 |
| 150*300 | 14 | 5 | 3.2 |
| 150*400 | 16 | 5 | 3.68 |
| 150*450 | 17 | 5 | 3.92 |
| 150*500 | 18 | 5 | 4.16 |
| 150*600 | 20 | 5 | 4.65 |
| Surface treatment |
|
Electro zinc plating: Thickness of coating >12um Application environment (Indoor): IDC, Factory, Hospital, Railway Industry, Electricity industry, Energy resources, automation industry |
|
Hot dip galvanized: Thickness of coating >60um Application environment (Indoor.Outdoor): Chemical Engineering, Railway Industry, Electricity industry, Energy resources, Wind power, solar energy |
|
Powder coating after zinc coated(Colored channel): Thickness of coating >60um Application environment (Indoor): Chemical Engineering, Railway Industry, Electricity industry , Energy resources, Wind power, solar energy |
|
Acid washing For stainless steel: Application environment(High corrosion occasions): Pharmacy Industry, Machinery and Equipment Automation Industry, Seabrone, Robotics , Food Industry |
Materials |
| Q235B(SS400B), Aluminum, Pre-galvanized steel,FRP, Stainless steel 304/316/316L |
MOSTLY ASKED QUESTIONS:
What is the type of our bussines?
We are a exporter and manufacturer, and have factories in China.
What are the trading terms we practice?
Generally, we practice FOB/CIF/C&F and DAP.
What are the payment terms we accept?
T/T, L/C, 30% deposite and 70% banlance against B/L, NEGOTIABLE
What is the delivery time?
Generally, it would take 10-20 days to finish the production for normal order quantity.
Can we provide the samples?
Yes, sample is free.
CERTIFICATION:(NEMA,CE,IOS)
