Help CenterSpray Booth, Dry Spray Booth
Related Products
-
Spray Booth, Paint Spray BoothUS$ 100 - 100,000MOQ: 1 Unit -
Powder Painting Line, Paint Booth, Painting PlantUS$ 1,000 - 10,000MOQ: 1 Unit
-
Automatic Spray Paiting Booth/Automatic Spray Painting Line/ Spray Painting MachineUS$ 70,000 - 180,000MOQ: 1 Set
-
High-quality Electrophoretic Painting Line for Car IndustryUS$ 1 - 100,000MOQ: 1 Set
-
Auto/Manual Spray Painting Booth/cabinet With Best PriceUS$ 1 - 100,000MOQ: 1 Set
- 1. Dry Spray Booth
Dry Filter Centrifugal Spray Booths are recommended when paint consumption is less or water is scarce. Dry spray booth is composed by the chamber body, exhaust system and mist processing device.
Types:
Dry Back- Side Draft
Dry Bottom- Down Draft
Dry spray booth advantages:
1) Low running costs fan, no cohesion agent, no need wastewater treatment, and less power consumption.
2) Small footprint, labor saving, no paint residue discharge and water quality inspection work.
3) Its construction is simple and low noise.
4) Low maintenance costs
Dry type spray booth disadvantages:
1) A large consumption of the filter.
2) The interior walls and baffles tend to accumulate paint grain, it must be cleared up.
3) If the maintenance is not in place there will be some fire hazard.
4) Because if the paint is not removed in time and get deposited inside duct, they are a fire hazard.
Contact us to customize Dry Filter Booths available in any sizes and formats to suit any applications.
We also make Open Type Spray Booths, open face spray booth, cardboard Filter Paint Booth, non-pressurized spray booth, pressurized spray booth, crossflow booth, semi-downdraft booth, side-downdraft booth downdraft booth.
Operating principle:
Air-supplying and exhausting devices start at the same time (Warm-up in winter), fresh air enters to the heating air-supplying unit through inlet filter from air inlet, and the processed airflow will be passed by the air-supplying unit to the static pressure chamber on the top of the booth. The airflow will be treated by the filter cotton on the bottom of the chamber and then entered in the painting booth in laminar flow way, which makes the remaining paint mists down along the airflow, avoiding them emission all round.
Technical features: | |
1 |
Made of light steel, safe and steady. |
2 |
The wall is made of seal composite insulation board, nice appearance and convenient construction. |
3 |
3D service wagon could be set in the painting booth for the conveying of all kinds of large workpieces. |
4 |
The operating area complies with occupational safety and health standards and the exhaust emission conforms to the state environmental protection standards. |
5 |
The waste gas concentration alarm device is set in every painting booth, when the waste gas concentration reaches the dangerous figure, the exhausting device will automatically emission the waste gas out of the booth. |
Main parts of the paint spraying booth | |
1 |
Chamber body |
2 |
Filter system |
3 |
Exhausting system |
4 |
Lighting system |
5 |
Waste gas treatment device |
6 |
Control system |
Product Catalog: | |
*Coating lines |
Automatic/Manual/Semi powder coating line; Automatic/Manual/Semi paint spraying line; Electrophoretic painting line; Electrostatic powder coating/painting line etc. |
*Coating booths |
Powder coating booth with large cyclone; Powder coating booth with small cyclone; Powder coating booth with recycling system; Painting booth; Water curtain painting booth, Sand blasting booth; Shot blasting booth etc. |
*Conveying systems |
Chain conveyor, Belt conveyor, Plate conveyor, Overhead conveyor and Power and free conveyor are all available according to the clients' requirements. |
*Coating ovens |
Drying oven and curing oven with various heating energy, like gas, electricity, diesel etc. |
*Coating machines |
Electrostatic powder coating gun (OURS-808 and OURS-2014); Airless paint sprayer etc. |
Our service: |
|
*Free design: |
Free drawing designed by our engineer according to the actual requirements of clients. |
*High quality and competitive price: |
We promise to provide high quality equipment with best price. |
*Customized equipment: |
Customized equipment completely based on the drawing. |
*Overseas installation and commissioning: |
On-site installation and commissioning of coating lines. |
*Warranty |
At least one year after the acceptance of the client. |
