Home > Consumer Electronics > Display & Accessories > LCD Module > 4.3 Inch 480x272 Tft Lcd Module Touch Panel With FT5206 IC
4.3 Inch 480x272 Tft Lcd Module Touch Panel With FT5206 IC
US$ 1 - 30
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Yunlea
Model Number:
YL-S99816D
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Multi Touch Screen 4.3 Lcd Tft Modules Touch Panel for Sale 2016US$ 1 - 30MOQ: 1 Piece -
Yunlea MStar 2133A IC 3.5'' Hvga 320x480 Tft Lcd Display Touch ScreenUS$ 10 - 30MOQ: 1 Piece
-
Yunlea Factory 24 Bit Rgb Interface Lcd Display 5" Touch PanelUS$ 10 - 34MOQ: 1 Piece
-
5" Touch Display 800x480 Dots Tft Lcd With Rgb InterfaceUS$ 10 - 34MOQ: 1 Piece
-
Five Points 800x480 5.0" Tft Lcd Panel Touch Panel 2016US$ 10 - 34MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Yunlea
Model Number
YL-S99816D
Type
Other, tft touch display
4.3 inch 480x272 tft lcd module touch panel with FT5206 IC
Skype:yunlea.sales
Product Description
What's specification of 4.3 inch TFT touch display?
---The specification of 4.3 inch touch screen--- | |
| Specification | |
| Size | 4.3 inch |
| Product name | 4.3 inch capacitive touch screen |
| Model number | YL043MY01 |
| Type | LCD + CTP |
| Struture | CTP(Glass+Glass)+LCD |
| Outline Dimension | 114x77x4.88mm |
| Active area | 95.04x53.86 mm |
| Resolution | 480x272 dots |
| Brightness | 250 to 300 available cd/m2 |
| Touch controller | FT5206 |
| Interface Of tft | 24 bits rgb interface |
| Interface of CTP | I2C |
| Surface Hardness | 6H |
| Transparency | 86%min |
| Touch Points | 5 points |
| Operating temp | -20 to 70 degree |
| General Business Clauses | |
| MOQ | 1 piece |
| Lead time | Samples in stocks,2~4 weeks for mass production |
| Trade Terms | EXW or FOB |
| Payment |
100% Paypal or T/T or Western union in advanc for samples , 50% T/T in advance and 50% before delivery for mass production |
| Warranty | 12 months |
| Package | Plastic Tray+Anti-Static Foam+Paper Card+Vacuum Bag+Carton |
| ---The picture of 4.3 inch touch screen --- |
|
|
|
|
