4 Stations EVA Foam Injection Molding Machine JL-198-4S
- 1000 Set / Sets per Month
- Guangzhou Shenzhen Hongkong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
6 Stations EVA Foam Injection Molding Machine JL-198-6S
-
10 Stations EVA Foam Injection Molding Machine JL-198-10S
-
Big Moulding Plate Full-auto EVA Injection Molding Machine JL-198
-
Sandal Making Machine JL-198
-
Factory Made in China EVA Injection Moulding Machine JL-198
-
Shoe last injection molding machine JL-198
Product Details
Condition | New | Production Capacity | 400-600pairs/hour | |
Place of Origin | Guangdong, China | Brand Name | Kingstone | |
Model Number | JL-198 | Voltage | 220v/380v/440v, 220v/380v/440v | |
Power(W) | 18.5KW | Dimension(L*W*H) | 9*4.7*3m | |
Weight | 23Ton | Certification | CE SGS, CE Approved | |
Warranty | 2 Years, 2 Years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
JL-198 SERIES
EVA Foam Injection Molding Machine
JL-198-4S
Special Feature |
Electric Control Unit
Touch-screen human-machine interface makes the parameter setting fast and easy; electric cabinet is stand alone to avoid malfunction caused by machine vibration.
Injection Unit
1. The injection system is optimized by a unique screw design with precise temperature control.
2. The repeatability is assured by the precise volumetric control and the proportional valves of pressure and flow.
3. Injection volume is sufficient to meet the production with multi-cavity molds.
4. Equipped with multi zone thermal control on each injector. Each zone is set individually in accord with different
characteristics of compounds and production conditions.
5. Precise transmission system with the sliding structure driven precisely by servomotor control system;
the movement of the injection unit is smooth, and the positioning is fast and accurate.
Mold-Holder Unit
1. To meet various productions, the mold holder is designed to be suitable for different types of molds such as one mold one pair, one mold two pairs, one
mold three pairs in small sizes.
2. The high clamping force of mold holder is realized with hydraulic cylinders, which can automatically compensate
the variation of mold thickness caused by temperature change.
3. The clamping system is equipped with two independent sets of cylinders at each station. The big hydraulic cylinders
averagely distribute the high clamping force on the whole surface of the mold to avoid flash.
4. The mold open stroke is long to make collecting parts and cleaning mold easily.
5. There are independent temperature control units for up and down mold plates in each mold holder.
The temperature of each mold is controlled with high precision to produce parts with stable quality.
Specifications | |||||||||
Machine model | JL-198-2S | JL-198-4S | JL-198-6S | JL-198-8S | JL-198-10S | ||||
Mould-clamping Unit | |||||||||
Work station |
| 2 | 4 | 6 | 8 | 10 | |||
Clamping force | TON | 190 | 190 | 190 | 190 | 190 | |||
Mould-holder dimensions | MM | 290*550*2 | 290*550*2 | 290*550*2 | 290*550*2 | 290*550*2 | |||
Mould height | MM | 100-250 | 100-250 | 100-250 | 100-250 | 100-250 | |||
Opening stroke | MM | 350 | 350 | 350 | 350 | 350 | |||
Injection Unit | |||||||||
Injector | SET | 1 | 2 | 2 | 2 | 2 | |||
Screw diameter | MM | 60/65 | 60/65 | 60/65 | 60/65 | 60/65 | |||
Max.injection volume | cm3 | 950 | 950 | 950 | 950 | 950 | |||
Injection pressure | kg/cm2 | 1000 | 1000 | 1000 | 1000 | 1000 | |||
Screw rotation speed | R.P.M | 0-165 | 0-165 | 0-165 | 0-165 | 0-165 | |||
Electricity Consumption | |||||||||
Heating power of injector | KW | 13 | 13 | 13 | 13 | 13 | |||
Hydraulic unit motor | KW | 33.5 | 33.5 | 33.5 | 33.5 | 33.5 | |||
Heating board of mold | KW | 49 | 62 | 75 | 88 | 101 | |||
Total electric consumption | KW | 95.5 | 108.5 | 121.5 | 134.5 | 147.5 | |||
Temperature control | Section | 4 | 4 | 4 | 4 | 4 | |||
Dimension and Weight | |||||||||
Machine dimension(L*W*H) | M | 5*4.7*3 | 7*4.7*3 | 9*4.7*3 | 11*4.7*3 | 13*4.7*3 | |||
Machine weight | TONS | 10 | 16 | 23 | 29 | 35 | |||
*Note:Above data only for reference. |
Finished Products |
Dongguan Kingstone Machinery Co., LTD. , headquarter located in Dongguan, has been researching and
developing from manufacturing footwear machines as well rubber machines for industrial application.
Kingstone is striving toward larger business scope to provide customers diversified machine designs, perfect
production quality with the best and fast service.
Dongguan Kingstone Machinery Co., LTD.,as one of the famous rotary plastic footwear injection molding machine
manufacturers in the industry, the industry first class rotary injection molding machine r&d and manufacturing base,
over the years with the product variety is complete, personalized type many, quality excellent, and is famous world
without time service in the industry, the product sells in distant markets the world nearly 30 countries and regions,
at the same time also in Turkey, Brazil, India and many other countries set up offices and agents.
