Home > Instruments & Meters > Optical Lens & Instrument > Optical Lens > RUIDE RTS862R TOTAL STATION
RUIDE RTS862R TOTAL STATION
US$ 2,530 - 2,760
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Ruide
Model Number:
RTS 862R
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
Ruide
Model Number
RTS 862R
Specifications
1.RUIDE RTS862R TOTAL STATION2.Reflectorless 300m
3.Shipout in 10 working days
RUIDE RTS862R TOTAL STATION
Item specifics
Place of Origin: Guangdong China (Mainland)
Brand Name: RUIDE
Model Number: RTS862
Accuracy: 2"
Color: Green & white
Battery: 2
Prismless:300m
| model | RTS-862R | RTS-865R | |
| TELESCOPE | |||
| image | erect | ||
| magnification | 30x | ||
| effective aperture | 45mm (distance meter: 50mm) | ||
| resolving power | 3” | ||
| field of view | 1°30’ | ||
| minimum focus | 1.0m | ||
| telescope length | 149mm | ||
| ANGLE MEASUREMENT | |||
| measuring method | absolute encoding | ||
| diameter of disk | 79mm | ||
| minimum reading | 1”/5” | ||
| detection method | horizontal: dual vertical: dual | ||
| unit | 360 | ||
| vertical angle 0° | 360°/400gon/6400mil | ||
| accuracy | 2” | 5” | |
| DISTANCE MEASUREMENT | |||
| single prism | 5km | ||
| triple prism | 8km | ||
| reflecting sheet | 700m | ||
| Prism less | 300m | ||
| unit | m/ft | ||
| accuracy | +(2+2x10-6·d)mm | ||
| w/o prism: +(3+2x10-6·d)mm in great conditions | |||
| measuring time (initial) | single fine measure: 0.7s; tracking: 0.3s | ||
| measuring system | basic frequency: 80mhz | ||
| wave length | 685nm | ||
| atmospheric correction | auto sensing | ||
| atmospheric refraction & earth curvation correction | auto correction. k=0.14/0.20 | ||
| reflector constant correction | auto correction | ||
| VIAL | |||
| circular vial | 8’/2mm | ||
| plate vial | 30”/2mm | ||
| COMPENSATOR | |||
| system | dual axis photoelectric detection | ||
| compensating range | +4’ | ||
| resolving power | 1” | ||
| OPTICAL PLUMMET (OR INTERNAL LASER PLUMMET) | |||
| image | erect | ||
| magnification | 3x | ||
| focusing range | 0.3m ~ ∞ | ||
| field of view | 5° | ||
| DISPLAY | |||
| type | LCD graphics, color and touch | ||
| INPUT MODE | |||
| type | touch screen; alphanumeric keys | ||
| DATA TRANSFER | |||
| RS232 | yes | ||
| USB interface | yes | ||
| Bluetooth | yes | ||
| STORAGE | |||
| internal memory(flash & card) | >10000 points or > 20000 coordinates | ||
| sd card | 2G SD card as default | ||
| BATTERY | |||
| battery | Ni-H rechargeable | ||
| voltage | 6v (dc) | ||
| operating time | up to 12 hours | ||
| OPERATION ENVIRONMENT | |||
| operation temperature | -20 ~ +50 | ||
| water and dust proof | IP66 | ||
| SIZE & WEIGHT | |||
| size | approximately 149mm x 145mm x 306mm | ||
| weight | 4.0kg (w/o battery and case) | ||
| 6.0kg (with battery and case) | |||
