Help CenterFOIF DSZ-2 Nivel
US$ 230 - 250
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
FOIF
Model Number:
DSZ2
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shanghai, China
Brand Name
FOIF
Model Number
DSZ2
Specifications
Easy to fit together DSZ2 level and FS1 micrometer, standard deviation 1km double run: 0.5mm/km
| Specifications: | DSZ2 | DSZ3 | |
| Standard deviation of 1KM double run | ≤±1.0mm | ≤±2.0mm | |
| DSZ2+FS1 | ≤±0.5mm | ||
| Telescope | erect | Erect | |
| Clear objective aperture | 45mm | 45mm | |
| magnification | 32X | 24X | |
| Field of view | 2.3m | 3.2m | |
| Shortest focusing distance | 1.6m | 0.7m | |
| Multiplication factor | 100 | 100 | |
| Additive constant | 0 | 0 | |
| Compensator | |||
| Working range | ±14´ | ±14´ | |
| Setting accuracy | ≤±0.3" | ≤±0.5" | |
| Setting time | ≤2s | ≤2s | |
| Sensitivity of circular level | 8´/2mm | 8´/2mm | |
| Operating temp | -30ºC+50ºC. | ||
| weight | 2.5kg | 2.0kg | |
| Parallel plate micrometer FS1(optional accessory) | |||
| range | interval | estimation | Net weight |
| 10mm | 0.1mm | 0.01mm | 1.25kg |
