Specifications
air compressor spring mechanical sealsuper quality spring mechanical seal
mechanical seal
We are a Hi-Tech company specialized in research, development, manufacture and distribution of Air compressor spare parts.
mechanical seal
mechanical seal
mechanical seal/grease seal /oil seal / shaft seal
Characteristic:
chanical seal with single lip ,type :35*50*8
2.temperature:Up to 250°C
3.highly corrosion resistance
Material |
Stainless |
Application |
Screw air compressor |
Size |
Various |
Performance |
Resistant corrosion |
Descriptions :
1.mechanical seal/grease seal /oil seal / shaft seal / lip seal / screw air compressor parts
2.Available for left-handed rotation, right- handed rotation, irrotational;
3.Available for single lip, double lips, three lips;
4.Small order is acceptable;
5. Customized specifications are welcome.
6.OEM and ODM orders are warmly welcome;
Properties of Products
1.We use lip material with lowest solid friction coefficient (Wet friction coefficient 0.02~0.04 ), and these oil seals with excellent self-lubricate and abrasive resistance, will not rub the shaft.
2.It can be interchanged with rubber oil seals, and sealing property more reliable.
3. Main used for internal combustion engines, screw compressors, axles, gearboxes and other dynamic rotating seal
4. Excellent self-lubricate and abrasive resistance,is an ideal oil-free lubrication sealing material
5. Extensive temperature range,can be long used between -180°C~+250°C
6. Capacity in resisting the corrodent ,such as strong acid,alkali, oxidizer.,with the excellent chemical stability.
Working Conditions
dium: mineral oil,synthetic oil,grease,water,acid,alkali,dissolvent,gasoline etc.;
2.temperature range:-180°C~+250°C
3.medium pressure:1 MPa;
4.Axis speed:~35m/s;
5.allowed axis pulsation:0.38mm;
6.allowed hole eccentricity:0.38mm.
Matching detail for some of item
No. |
Specification of Mechanical Seal |
Type of the Lip |
Coupling Sleeve |
Model of the Machine |
1 |
37*51*10 |
Double |
30*37*38 |
Atlas 15HP2901056100 |
2 |
40*62*8 |
Double |
35*40*20 |
Rodcomp 15HP B60 |
3 |
40*62*8 |
Single |
Rodcomp20-30HP B101 |
|
4 |
50*72*8 |
Double |
45*50*25 |
Rodcomp50HP B170 |
5 |
70*90*10 |
Double |
60*70*40 /30/28 |
Rodcomp75HP B201 |
6 |
70*90*10 |
Double |
60*70*40 |
CompAir75HP |
7 |
70*90*10 |
Single |
CompAir75HP |
|
8 |
35*50*8 |
Single |
30*35*30 |
CF50G |
9 |
35*50*12 |
Double |
30*35*30 |
GHH15-20HP CE55 |
10 |
35*47*7 |
Single |
||
11 |
45*65*12 |
Double |
40*45*30 |
GHH70 Handpiece(QS70) |
12 |
45*60*8 |
Single |
||
13 |
68*100*12 |
Double |
60*68*45 |
GHH100HP(CF110/CF128J) |
14 |
68*90*10 |
Single |
||
15 |
68*90*10 |
Double |
60*68*45 |
GHH100HP(CF128LG) |
16 |
60*80*8 |
Single |
50*60*40 |
Fusheng 30HP |
17 |
60*80*8 |
Double |
50*60*40 |
|
18 |
65*90*10 |
Single |
55*65*45 |
Fusheng 50HP |
19 |
65*90*10 |
Double |
55*65*45 |
|
20 |
68*90*10 |
Single |
60*68*45 |
Fusheng 75-100HP |
21 |
68*90*10 |
Double |
60*68*45 |
|
22 |
100*120*10 |
Single |
85*100*55 |
Fusheng 150HP |
23 |
68*90*10 |
Double |
60*68*45(90.00) |
ECOAIR 100HP |
