Specifications
XH47IIX double sides offset press machine, double sides single color offset press machinedouble sides offset press machine XH47IIX, double sides single color offset press machine, double sides single color offset press machine
Features:
1. Double sides offset press has upper and lower six-roller unit structure, the machine could achieve single pass duplex printing, high degree of automation, heavy machine structure, whole cast iron wall panel; latitudinal feeding; fast version of clip; frequency control;
2. PLC microcomputer control; photoelectric automatic clutch pressure; motor-driven is no-class water supply; accurate positioning; four rows of high-profile delivery teeth could reduce paper adhesion;
3. Electrostatic process; electromagnet energy is significant energy saving.
Technical data of double sides single color offset press machine:
Model |
XH47DLM |
XH56DLM |
XH62DLM |
Max paper size |
470*365mm |
560*400mm |
620*450mm |
Max printing area |
450*345mm |
550*375mm |
605*440mm |
Print plate size |
470*395*0.15mm |
560*420*0.15mm |
620*480*0.15mm |
Rubber blanket size |
470*420*1.95mm |
560*460*1.95mm |
616*505*1.95mm |
Paper type |
40-300gsm |
||
Number of ink rollers |
14 pieces (3 form ink rollers each unit) |
||
Number of dampening rollers |
5 pieces (2 form water rollers each unit) |
||
Registration mechanism |
Roller type side lay |
||
Printing speed |
2000-8000 sheets/hour |
||
Motor power |
Main motor 1.5kw /220V, air pump motor 0.75kw/220V |
||
Machine size |
2305*858*1650mm |
2300*958*1650mm |
2660*1200*1800mm |
Weight |
1150kg |
1350kg |
1550kg |
About XSHEEN Technology:
Any requirements can immediately contact me on or add Skype: xsheen2008
