Factory Single Color Heidelberg Offset Printing Machine

Name: Factory Single Color Heidelberg Offset Printing Machine
Brand: XSHEEN
SKU: 109545753

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Shanghai, China

Shanghai Xsheen Machine Electron Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai beijing

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Flatbed Printer

Place of Origin Shanghai, China

Brand Name XSHEEN

Model Number XH47S

Usage Bill Printer, Card Printer, Label Printer, Paper Printer, Tube Printer

Automatic Grade Automatic

Voltage 220V

Gross Power 2200W

Dimensions(L*W*H) 1730x880x1200

Weight 400KG

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

factory single color heidelberg offset printing machine

XH47A Single color Offset press can adjust printing speed. It is practicable & convenient type offset

printing machinery.

In addition to the 47A model’s function, it has the NP system with versatile functions, for simultaneous

operations for numbering,

perforating and resin letter-press imprinting. The swing open of the numbering inking unit, opened at

a 120 degree angle, allows for

easy mounting of the numbering heads. The numbering inking unit with 2 form rollers enables both

enough density printing and

solid printing, allowing wider range applications. Hamada’s original concave perforation roller

rovides simultaneous vertical and

cross perforation. It eliminates the shock when pressing the blades, and provides an accurate cut.

Model	XH47S	XH47SNP
Max. paper width(mm)	470×365	470×365
Max. image size(mm)	460×345	460×345
Min. paper size(mm)	210x297	210x297
Plate size(mm)	470x380	470x380
Rubber blanket size(mm)	470x420	470x420
Overal dimension(mm)	1730x880x1200	1730x880x1200
Register device	Side pull guide
Paper weight	28~250gsm	28~250gsm
Power	220V50Hz	220V50Hz
Printing speed	2000~7000 pcs/h	2000~7000 pcs/h
Number capacity:	Lateral: 7 row x 7 column=49 Vertical: 5 row x 8 column=40 Ink roller: 6 pcs (Ink fountain roller: 2 pcs)
