XH256IIG-NP double colors numbering offset press
XH256IIG-NP double colors numbering offset press with Co-pneumatic pressure
Model |
XH256IIG-NP |
Max. paper size |
560x390mm |
Max.printing area |
540x370mm |
Paper weight |
28~250gsm |
Printing speed |
2000~7000 sheets/hour |
Plate size |
560x420mm |
Blanket size |
560x460mm |
Ink roller |
16 pieces(3 ink form rollers) |
Power of primary motor |
2.2kw |
Power of air-pump motor |
0.55kw |
Power supply |
220V/50Hz |
Dimension |
2900x1040x1440mm |
Net weight |
2300kgs |
Horizontal numbering machine |
7 lines*9rows=49 |
Vertical numbering machine |
5lines*8rows=40 |
Min. perforating spacing |
Horizontal:5mm; Vertical:25mm |
NP Ink roller number |
6 rollers(2 rollers against ink roller) |
|
Standard configure: 1. Static electricity eliminator; 2. Centralized lubricating system; 3. Weko power sprayer 4. Coding supporter: 4pcs on numbering part; 5. Code drawer: 4 pcs; 6. Resin plate cylinder:1pc; 7. Perforating knife: 1 pc | |
|
Detailed Product Description 1) Capability: Inking device of each unite has 16 ink rollers including 3 ink form rollers, guarantee the high precise printing quality, and can print double color, which can improve the efficiency and reduce the cost. Advanced ink feeding system, consisting of 16 ink form rollers including 3 ink rollers, ensure top quality prints 2) Easily operate: water supplying, ink supplying and platform pressing each unites can be finished at different lever with the same handle. Joint pressure of printing rollers is controlled with an electric eye, which is more reliable and easy to be regulated. 3) Accurate orientation: adopt front lay and double-side pull guide for orientations, also install with tune-up devices for feed table, its side lay, plate cylinder, and No.2 unit. 4) Adopt independent ink system and damping system, can freely adjust feeding, best meeting various demands of different printing matters, more suitable for color printings. 5) Presetting counter: automatically stop feeding paper once preset quantity task are completed. 6) Double detect device: detect double sheets and multiple sheets, and automatically eliminate double and multiple sheets. Double turn-around function: ensure the sufficient dryness of ink demanding of special printing matter. 7) Sprayer device: make spraying and printing run in synchronization, prevent printing matter from dirty 8)Centralized oil feed system: more convenient for maintenance 9) Touch device: realize rapid loading and unloading plate, easier operation and better safety. | |
