Specifications
bill folding and collating machine, bill numbering and collating machinebill folding and collating machine, bill numbering and collating machine, continuous paper offset printing machine
1. XH500DK, bill puncher/ folder machine, creaser folder
Features:
XH500DK Machine cast iron wall panels and machine base, frequency control, work stable, punching accuracy, hole plate lap 44 holes, according to the international standard production, enabling automatic punching, pressure horizontal, vertical broken line, folding and other processes.
Technical data:
Model | XH500DK |
Max paper width: | 533mm(20in”) |
Max web diameter: | 1000mm(40in”) |
Punching diameter: | 4+0.1mm |
Paper quality | 30-70g/m2 |
Folding length: | 8in-15in |
Working speed | 8mpm to 100mpm |
Power | 1.5KW |
Weight | 1600KG |
Machine size | 3130(L)*1070(W)*1360(H)mm |
2. Offset printers XH-470SPJ offset bill printer machine
Features:
XH470SPJ Bill printing machine adopt imported feeding tracks and advanced PLC system, touch screen operation, printing with high precision, high speed, up numbers printed can be realized, double colors printing with good quality.
Technical data:
Max paper width | 470mm |
Max printing area | 454*345mm ( 7in-14in ) |
Tracking printing precision | <0.08mm |
Printing speed | 2000-10000 sheets/hour |
Paper quality | 30-170g/ m2 |
Power | 1.5KW/220V/50HZ |
Machine weight | 670KG |
Machine size | 1750(L)*1050(W)*1550(H)mm |
3. Bill binding machineXH-450
Features:
Imported PLC programmable controller, imported frequency conversion stepless speed regulation, and optoelectronic feed detection, automatic drawing code, coding, photoelectric control permits automatic decline, paper automatic lifting equipment, pre-style counter, with pages, play yards, claws set, cut in one, complete functions and easy operation
Technical data:
Application scope | Various types of computer paper, carbonless paper |
Max paper width | 450mm |
Max layer rate | 6 layers |
Max numbering machine | 42 |
Min numbering machine | 1 |
Hole diameter | 4+0.1 mm |
Working speed | 30-100/min |
Power | 0.75KW/220V |
Machine weight | 800KG |
Machine size | 3600(L)*940(W)*1100(H)mm |
About XSHEEN Technology:
Any requirements can immediately contact me on or add Skype: xsheen2008
