Specifications
XH500DK Bill Punching&Folding MachineXH500DK Bill Punching & Folding Machine
Computer bills & forms production line adopts advanced technology and rich experiences at home and abroad, including Panasonic servo system from Japan, Mike controlling sytem from Weihai, Schineider Variable-frequence governor from France, MOORE feeder from USA, Seven-grades grinding gear with high precision, NSK bearings & TSUKATANI perforating knife from Japan etc. It is a high-precision machine which is produced by advanced fabrication plant.
Features:
XH500DK Machine adopt cast iron panels and base, frequency control, work stable, punching accuracy.44 holes in one plate lap, according to the international standard, automatic punching, horizontal creasing, vertical creasing, folding.
Technical data:
Model |
XH500DK |
Max paper width: |
533mm ( 20in”) |
Max paper roll diameter: |
1000mm ( 40in”) |
Paper quality |
40-150g/m2 |
Working speed |
5-120m/min |
Punching diameter |
4±0.1mm |
Paper hole space |
12.7mm |
Folding length |
8in-15in |
Power |
220V, 50HZ, 1.5KW |
Weight |
1600KG |
Machine size |
2350(L)*1150(W)*1550(H)mm |
About XSHEEN Technology:
Any requirements can immediately contact me on or add Skype: xsheen2008
