Help CenterXC46-71/122A-CWP Automatic High Speed Disposable Plastic Plates and Bowls Making Machine
Related Products
-
XC46-71/122A-CWP Automatic New Disposable Plastic Plates and Bowls Vacuum Forming MachineNegotiableMOQ: 1 Set -
XC46-71/122-CWP Automatic New Box Egg Tray Making MachineNegotiableMOQ: 1 Set
-
XC46-71/122A2-WP New Automatic High Speed Small Thermoforming MachineNegotiableMOQ: 1 Set
-
XC46-71/122A2-WP New Automatic High Speed Plastic Tray Machine MakingNegotiableMOQ: 1 Set
-
XC46-71/122A2-WP New Automatic High Speed Egg Tray Machine MakingNegotiableMOQ: 1 Set
Specifications
1.Save up 30-40% total power consumption2.All production data are easy to store and recall
3.Save up 10-20% sheet material
Useage:
The disposable plastic plates and bowls making machine is suitable for making all size packing containers, in open-type with thin-wall ,by using roll-sheet , under high-speed vacuum suction-forming processing .The products out of disposable plastic plates and bowls making machine can be used for the package of foods .native-products,tourist-goods,textile,medical, toy,cosmetic,electrical elements and daily used hard-ware ,etc .
Sheet fit to the machine
Starch-deposit sheets ,light-deposit sheet ,environment sheet APET ,PETG .Color sheets :PVC,HIPS,PET,PS,PP, EPS, etc.Fiber-coating-sheet.
Structure features
1.The disposable plastic plates and bowls making machine combine with mechanical ,pneumatic and electrical integration fully computer control .Touch Screen easy operation.
2.Production Acounting ,can set automatic stop or advance alarm function ;Date Memorization function can store 230 data and para .
3.Inverter Feeding Driving ,length stepless adjust ,Feeding accurate,stable and high speed.(Max Feeding Speed 1000mm /per second)
4.Temperature Control system , fully computer intellectual temperature control , short heating time ( only 3 min from 0-400 degree ) ; stable ( not effect by outside voltage and temperature fluctuate is less than 1 degree) ; lower power consumption 15% , longer life of far infrared ray ceramic heater
5.Heater has deflection over structure ,which could close whole row of the porcelain heaters when the width of sheet is≤580mm.It can reduce power consumption 16%.
6.Heating Temperature control , individual heating control , Touch Screen input , mini-adjustment precision and heating temperature uniformity .
7.Aadvance feeding with the heating time automatic memory function ,machine could start production from the first feeding .
8.Two-step vacuum ,Two time of up-mould ,Mould Shaking Function ,Mould delay .
9.Product Silicon Sprayer Device .
10.Up/down Mould electric stroke adjust ,easy to adjust under the mould matched situation .It could improve the accurate of moulding and quality of finished production .
11.Back acting plate position motor adjust .
12.Up/down mould match into cushion ,avoid crushion and improve the match speed .
13.Up/down Guiding Leader with self-lubrication bearing couple .stable production and durable structure ,it could assure the high quality of finished products.
14.The width of feeding chain synchronizate and separate motor adjust .
15.Heaters with moving-out structure ,could move out under the malfunction situation ,it could save the sheet materials .
16.Cylinder Sheet Loading structure ,easy for workwoman operation .
17.Up / Lower mold stroke double adjustment , upper mold electromotion adjust under mold clamed situation )
18.Cutting unit with double clamping cutting function ,could produce Male/Female and various different of products slide cutting .
19.Cutting structure adopts special convert structure ,can optimize the working space .The separate stacking car easy finished products stacked .Movement Guide Pole easy stack .
Technical Parameter
Model No. |
XC46-71/122A-CWP |
|
Suitable Sheet Width(mm) |
460-710 |
|
Thickness(mm) |
0.1-2.0 |
|
Max Roll Sheet (mm) |
600 |
|
Up Mould Stroke (mm) |
500 |
|
Down Mould Stroke(mm) |
350 |
|
Max Forming Area(mm2) |
680×1200 |
|
Max Forming Height Protruding(mm) |
200 |
|
Max Forming Height Concave(mm) |
150 |
|
Capacity (Cycle/min) |
4-10 |
|
Cooling Outlet |
Outlet |
4 PCS |
Spray |
11 PCS |
|
Air Source |
Air Vol. (m3/min) |
≥2 |
Pressure(MPa) |
0.8 |
|
Water Consumption |
4-5 Cube/Hr |
|
Vacuum Pump ( Outlay ) |
Busch R5 0100 |
|
Power Supply |
380V/ 220V 50Hz 3Phase 4 line |
|
Heater Power(Kw) |
54 |
|
General Power Max(Kw) |
62.52 |
|
Dimension(L×W×H)(mm) |
8070×1750×2525 |
|
Weight(kg) |
4900 |
|
