Help CenterLXC85-135/190-W Automatic Cooling Tower Filling Forming Machine
Related Products
-
LXC85-135/190-W High Speed Automatic Cooling TowerNegotiableMOQ: 1 Set -
LXC85-135/190-W High Speed Automatic Pvc Fill for Cooling TowerNegotiableMOQ: 1 Set
-
LXC85-135/190-W High Speed Automatic Cooling Tower Pvc FillerNegotiableMOQ: 1 Set
-
LXC85-135/190-W New Design Automatic High Speed Small Cooling TowerNegotiableMOQ: 1 Set
-
LXC85-135/190-W New Full Automatic Cooling Tower Filling MaterialNegotiableMOQ: 1 Set
Specifications
Automatic Cooling Tower Fill Forming Machine. For making cooling tower fills from PVC,PSCooling Filling Forming Machine
Usage:
This Cooling Tower Filling Forming Machine is widely used for making vacuum formed products like cooling tower fills from PVC, PS and so on.
Operation Principle:
Operation processes: The heated and soften plastic sheet are being vacuum formed in the mold in order to get the various finished products. The operation processes are: sheet-feeding—heated—forming—side trimming— crosscut.
Structure feature:
01. The Cooling Tower Filling Forming Machine is combined with pneumatic , mechanical and electricity driving, adpot PLC control . It can achieve sheet feeding , heating , forming , side trimming , crosscut into continuous job .
All working action can adjust uder non-stop production . It’s convenient and high capacity , easy for operation .
02. The working method can crosscut by different pattern of fill .
03. Servo Motor feeding , Feeding Length stepless adjustabe , precision and reliable.
04. Cutting Unit with Servo Motor Driving , Electrical & Pneumatic adjustable by different length crosscut ( the length must be longer than each forming mold length ) .
05. Forming area is big and easy for mold installation & replace.
06. Cylinder Roll Sheet Loading , Feeding Chain manual adjust.
07. Upper , Lower mold stroke limited , Up mold descend motor adjust.
08. Forming area double adjustable , can save the sheet material .
09. Back acting plate adopt double cylinder method , motor setting position .
10. Two step of Vacuum .
11. Fan Blowing , Air Spray Cooling Device .
12. Heater adopt individual heating temperature control . ( Point to Point )
13. Advance sheet feeding , heating parameter can automatic adjust.
Technical Parameters:
Sheet size |
width 700-1350mm, thickness 0.12-1.2mm |
Max. sheet sending length |
1900mm |
Max. forming area |
1320×1880mm |
Capacity |
4-10cycles/min |
Power usage |
415V(3 phases 4 lines), max. 112.93Kw total |
Air consumption |
≥2 m³/min. (prepare by client). |
Operation air pressure |
0.7Mpa(air source 0.8-1mpa). |
Dimension(L×W×H) |
8070×3920×2575mm |
Weight |
about 3200kgs |
