Help CenterInventory Secondhand Steam Turbine
Related Products
Specifications
Inventory industrial steam turbine can be used for industrial driving unit for industrial fans, water pumps or other industrial1. B1.5-2.35/0.58 Backpressure steam turbine:
-Inlet steam pressure: 2.35MPa;
-Steam temperature: 400
-Exhaust steam pressure: 0.58MPa;
-Max. throttle flow: 25t/h;
-Rated capacity: 1.5MW.
-Delivery date: 1985.
-Product state: Inventory product (original packing);
-Manufacturer: Shanghai Steam Turbine Works.
-Quantity: 1 set
This steam can be used for a thermal captive power plant, or industrial driving unit. We can supply a matched generator together with a boiler for an integrative solution for a 1.5MW biomass fuel or coal fired captive power plant.
2. B0.5-2.35/0.58 Backpressure steam turbine + 500kw generator:
-Inlet steam pressure: 2.35MPa;
-Steam temperature: 400
-Exhaust steam pressure: 0.58MPa;
-Max. throttle flow: 10t/h;
-Rated capacity: 0.5MW.
-Generator capacity: 0.5MW, 400V/50Hz/3phase
-Delivery date: 1985.
-Product state: Inventory product (testing steam turbine generator unit);
-Manufacturer: Hangzhou Steam Turbine Works & Hangzhou Generating Equipment Factory
-Quantity: 1 set
This unit can be used for a thermal captive power plant, or industrial driving unit. We can supply complete set of steam turbine generating unit for a captive power plant, or supply separately for steam turbine and generator.
3.B0.3-1.27/0.49 Backpressure steam turbine + 300kw generator:
-Inlet steam pressure: 1.27MPa;
-Steam temperature: 320
-Exhaust steam pressure: 0.49MPa;
-Max. throttle flow: 10t/h;
-Rated capacity: 0.3MW.
-Generator capacity: 0.3MW, 400V/50Hz/3phase
-Delivery date: 1985.
-Product state: Inventory product;
-Manufacturer: Shanghai Steam Turbine Works & Fenxi Electrical Machine Co.,Ltd.
-Quantity: 1 set
This unit can be used for a thermal captive power plant, or industrial driving unit. We can supply complete set of steam turbine generating unit for a captive power plant, or supply separately for steam turbine and generator.
The steam turbine will be supplied together with following services:
-Customized engineering design according to prevailing standard, main equipment will be accordance with ASME code, control system and electrical system will be accordance with IEC standard;
-Customized boiler with ASME stamp, or without ASME stamp;
-Customized boiler according to clients requirement for the fuel;
-The steam turbine will be guaranteed in good operating, spare parts supply and maintenance service;
-The generator of 1.5MW can be 50 Hz or 60 Hz with different voltage to adapt the situation in different area and countries;
-The control system can be used by instrument control, PLC control, or DCS control against on the clients requirement of investment cost control;
-Supervision for installation at construction site to save clients installation cost;
-Flexible training manner for operators, it can be chosen by client, training at construction site, or in China;
-Spare parts supply in time;
-Exported package accordance with the requirement of sea transportation.
-Providing the service of third part inspection to the exported equipment.
