Specifications
pvc compound for cable jacketvirgin PVC resin material
black red or as request
use for cables,wires,hose,etc.
♦ About Suzhou Mega Plastics
Suzhou Mega was established in 2001, and betgan to develop environmentally conscious polymer compounds. Now, we are known as the lead manufacturer and supplier of PVC and LSHF compounds to producers around the world. Our customers come mainly from China, Taiwan, North America and Africa. Quality products with a commitment ot excellent customer service, Suzhou Mega manufactures more than 20,000 tons of compounds that comply with various global safety standards, such as the Rosh, UL and REACH, which are shipped to domestic and oversea markets alike.
♦ Product Application
Apart from being used widely in the cable and wire industry, Mega's polymer compounds have a variety of applications, such as in the automotive, tool handle, toys, medical tubing and other industrial and residential applications.
For each application, our engineers at Mega will customize and design particular formulation and process to meet each requirement of the compound, including hardness, color and cost. They will cooperate closely with customers to make sure that each specification of the compound is met.
By using our PVC granules, users' production efficiency can be highly improved, since our granules have very fast wire outletting speed and smooth appearance.
♦ Expertise
Vinyl resin is an extremely versatile thermoplastic polymer that is suitable for a wide range of applications. Vinyl resin attains its usefulness through various additives that allow it to be used in various markets and products: from automotive parts to medical tubing, from building construction to children's toys. Vinyl is very durable, and relatively cost efficient. It also meets stringent regulations and requirements mandated by many industries.
Suzhou Mega ensures that our production processes accord with international standards, such as: UL, ROHS, REACH and SONY. Our environmentally-friendly production process ensures that we meet your quality needs.
| Raw PVC granules for China Car wire/cable standard | ||||||
| Test Items | Unit | Typical Value | Reference standard | |||
| M-CV-5051 | M-CV-5052 | M-CV-5053 | M-CV-5054 | |||
| Tensile strength | MPa | ≥16 | ≥16 | ≥16 | ≥16 | GB/T8815-2008 |
| Elongation at break | % | ≥150 | ≥150 | ≥150 | ≥150 | GB/T8815-2008 |
| low temperature brittleness | °C | -20 | -20 | -20 | -20 | GB/T5470-1985 |
| 200°CThermal stabilization time | min | ≥120 | ≥120 | ≥80 | ≥80 | GB/T8815-2008 |
| 20°C Volume resistivity | Ω·cm | ≥1*1012 | ≥1*1012 | ≥1*1012 | ≥1*1012 | GB/T8815-2008 |
| Dielectric strength | MV/m | ≥20 | ≥20 | ≥20 | ≥20 | GB/T8815-2008 |
| Aging temperature | °C | 136±2 | 136±2 | 100±2 | 100±2 | GB/T8815-2018 |
| Aging time | hrs | 168 | 168 | 168 | 168 | GB/T8815-2018 |
| Tensile strength after aging | % | ±20 | ±20 | ±20 | ±20 | GB/T8815-2018 |
| Elongation after aging | % | ±20 | ±20 | ±20 | ±20 | GB/T8815-2018 |
| Thermal shock | Pass | Pass | Pass | Pass | GB/T25085-2010 | |
| Hardness | SA | 90±2 | 82±2 | 90±2 | 82±2 | GB/T8815-2018 |
| Heat distortion | % | ≤40 | ≤40 | ≤40 | ≤40 | GB/T8815-2018 |
| Abrasion strength | % | ≤0.25 | ≤0.25 | ≤0.25 | ≤0.25 | GB/T3960 |
♦ Standardized Office Space:
♦ Clean & Organized Factory:
♦ Variety of Colours:
♦ Organized Laboratory:
♦ Mega Certification:
♦ Contact Information:
To make you an offer ASAP, we need technical data listed below:
- Density
- Color
- Shore hardness
- Mechanical properties
- Electrical properties
- Flame-retardant grade
- Others
