Specifications
1.xlpe crosslinkable2.Good plasticization
3.Uniform color
4.No significant impurities
5.Excellent product quality
♦ About Suzhou Mega Plastics
Suzhou Mega was established in 2001, and betgan to develop environmentally conscious polymer compounds. Now, we are known as the lead manufacturer and supplier of PVC and LSHF compounds to producers around the world. Our customers come mainly from China, Taiwan, North America and Africa. Quality products with a commitment ot excellent customer service, Suzhou Mega manufactures more than 20,000 tons of compounds that comply with various global safety standards, such as the Rosh, UL and REACH, which are shipped to domestic and oversea markets alike.
♦ Product Application
Apart from being used widely in the cable and wire industry, Mega's polymer compounds have a variety of applications, such as in the automotive, tool handle, toys, medical tubing and other industrial and residential applications.
For each application, our engineers at Mega will customize and design particular formulation and process to meet each requirement of the compound, including hardness, color and cost. They will cooperate closely with customers to make sure that each specification of the compound is met.
♦ This Model
MG80017-90(J/H) 90°C irradiation cross-likable Flame-retardant polyolefin low-Smoke non-halogen insulating(sheating) compound
MG80017-105(J/H) 105°Cirradiation cross-linkable Flame-retardant polyolefin low-Smoke non-halogen insulating(sheating) compound
MG80017-125(J/H) 125°C irradiation cross-linkable Flame-retardant polyolefin low-Smoke non-halogen insulating(sheating) compound
INTRODUCTION
Irradiation cross-linkable flame-retardant polyolefin low-Smoke non-halogen compound is based on polyolefin resin, which is mixed with non-halogen flame retardant, cross-linkable agent, and other process agent, to knead, plastify, and then extrude into pellets. It has excellent mechanical and electrical properties. It is oil resistant, flame-retardant, and has excellent processing properties.
Most importantly though, Suzhou Mega's irridation cross-linkable compound has the advantage of having no halogen and giving out little amount of smoke during production. This product can be used in: power cable, control cable, marine cable, optical cable and signal cable etc.
Vinyl resin is an extremely versatile thermoplastic polymer suitable for a wide range of applications. Vinyl resin attains its usefulness through various additives that allow it to be used in a multitude of markets and products – everything from automotive parts to medical tubing, from building and construction to children's toys. Vinyl is very durable, relatively cost efficient and meets stringent regulations and requirements mandated by many industries
TECHNICAL DATA SHEET
| Test Items | Unit | Typical Value | ||
| MG80017-90(J/H) | MG80017-105(J/H) | MG80017-125(J/H) | ||
| Density(23°C) | g/cm3 | 1.45 | 1.44 | 1.45 |
| Tensile strength | MPa | 12.3 | 12.7 | 13.1 |
| Elongation at break | % | 220 | 210 | 200 |
| Hot setting test | 200°C x 15min,0.2MPa | |||
| Elongation under lood | % | 65 | 70 | 80 |
| Permanent elongation after cooling | °Cxh | 121x168 | 136x168 | 158x168 |
| Retaintion of Tensile strength | % | 109 | 112 | 110 |
| Retaintion of Elongation at break | % | 89 | 87 | 85 |
| low temperature impact Brittleness | °C | -25 pass | -25 pass | -25 pass |
| 20°C Volume resistivity | Ω.cm | 5.6x1014 | 3.7x1014 | 4.5x1014 |
| Dielectirc strength | MV/m | 26 | 28 | 27 |
| Oxygen index | % | 34 | 35 | 33 |
| Acid gas emission | mg/g | 0 | 0 | 0 |
| pH | 5.9 | 6.0 | 5.8 | |
| Conductivity | μs/mm | 0.8 | 0.7 | 0.5 |
| Dm(1.0mm) Smoke density | flame | 56 | 61 | 54 |
| non-flame | 152 | 159 | 162 | |
Irradiation dosage:
Irradiation dosage is different from the cable and da, genlerally 10-15MRAD recommended.
♦ Structured Office
♦ Clean & Organized Warehouse
♦ Product Display:Variety of Colours
♦ Advanced Laboratory
With highly-skilled staff and well-equipped laboratory, Suzhou Mega triple tests each of the compound that it produces to ensure the products consistently meet ech customer's requirements. We are now able to perform the following testing procedures: 1) tensile strength, 2) elongation, 3) gravity, 4) air oven aging, 5) color meter, 6) water resistance, 7) oil resistance. Additionally, Mega also uses atomic abosroption spectrometry (Aa) and X-Ray spectrometry to analyze environmental sensitive elements of raw materials, so as to ensure that the products comploy withRoSH standards.
♦ Industry Listings and Certifications
Product Safety: UL, CSA, VDE & CCC
Quality Management System:ISO9001-2004
Environment Managemetn: ISO14001-2004
♦ Green & Environmental
Mega is extremely conscious of the environment, and is therefore committed to provide customers with accurate information about our products and production processes. We ensure that these processes align with and exceed industry standards. We are proud to work cooperatively iwth each of our customers to address their product and market needs. We are committed to continue to find new ways to formulate new and existing products that will have minimal hazardous ingredients and effects on the environment. Our green compliance system will continue to be Mega's core competitive advantage as the market shifts and desire better and higher quality products, while causing minimal harm to the environment.
♦ Contact Information
If you would like to have more information about our products or are interested in establishing business relationship with us, feel free to reach us at:
Tel: 86-512-65275752
Fax: 86-512-65277403
Phone: 86-13404235070
Website:
