AgZnO Electric Contact

Name: AgZnO Electric Contact
Brand: Saijin
SKU: 109494549
Availability: InStock

US$ 0.005 - 0.2 MOQ: 5000 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Saijin

Wenzhou Saijin Electrical Alloy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Saijin

Specifications

1.Material: AgZnO
2.High quality with competitive price
3.Certification:Rohs,SGS
4.MOQ:5000 pcs

AgZnO Contact:

Features:

(1) ZnO, one type of material in AgznO contact, has comparatively higher thermal stability

(2) The welding resistant and resistance against arc erosion of the contact making ZnO material a higher product

(3) The AgZnO contact material has higher welding resistance and low arc erosion with strong magnetic arc blowing under large switching capacity

(4) AgZnO contact material is innocuous and has no pollution to the environment

(5) AgZnO contact material is mostly suitable for contactors and circuit breakers with large capacities

Chinese National Standard of Bemetal Rivets

Item	Head Diameter D mm	Head Thickness T mm	Face composite layer Thickness S mm	Tail Diameter d mm	Tail Length L mm	R mm	Demoulding Angle
Limit Deviation	±0.1	±0.05	S≤0.4±0.060 S0.4±0.60	-0.02 -0.10	+0.150	R≤6±1 R>6±2	±2
Basic Dimension	2.5	0.6,0.8,1.0	0.3-0.4	1.2,1.5	1-2	4,6	9,10,11,12
	3.0	0.8,1.0,1.2	0.35-0.50	1.5		6,8
	3.5			1.5,2.0	1-3.0
	4.0	1.0,1.2,1.5		2.0		8,10
	4.5			2.0,2.5
						10,15
	5.0	1.0,1.2 1.5,2.0	0.40-0.60	2.5
	5.5			2.5,3.0		15,20
	6.0			3.0
	6.5	1.2 1.5 2.0	0.50-0.70	3.0,3.5
						20,25
				3.5,4.0
	7.0
	8.0
