Help CenterCustomized Electrical Oxidation Contact Sheet Tips
Related Products
-
Welding Electrical Contact SheetsUS$ 0.005 - 0.2MOQ: 10000 Pieces -
Power Metallurgy Electrical Contact Sheets Used in ThermostatsUS$ 0.005 - 0.2MOQ: 10000 Pieces
-
Customized Electrical Oxidation Contact Sheet Tips With RoHS ApprovedUS$ 0.005 - 0.2MOQ: 5000 Pieces
-
Customized Electrical Oxidation Contact Sheet Tips for Washer With ISO9001 ApprovedUS$ 0.005 - 0.2MOQ: 10000 Pieces
-
Metallurgy Silver Alloy Contact SheetsUS$ 0.005 - 0.2MOQ: 5000 Pieces
Specifications
1.Over 10-year experience2.advanced equipment
3.high in quality and favourable price
4.fast delivery
5.ISO9001,SGS,RoHS
Materials:
Ag,AgCdO,AgSnO,AgSnOInO,AgZnO,AgNi,etc
Advantages:
Wenzhou Saijin Electrical Alloy Co., Ltd has our own manufacturing base to supply series of Powder Metallurgy Sheets: such as Powder Metallurgy Tips, Powder Metallurgy Contact, Button Contacts, Semi Tubular Contact Rivets and other special contacts.
- Cooperation: Simens,PEUGEOT,MAZDA ,SANYO etc
- We have ability to supply in large volumes in shortest time.
- Variety of specifications and shapes can be available as per customers' requirement, especially for Button Contacts, and Tri-metal Contact Rivets, etc.
- We promise we have superiority over others in fast delivery, competitive price and high quality.
Features
AgNi sheet
(1) AgNi contact material contains 10% to 40% Ni
(2) Produced by powder metallurgical production, with low and stable contact resistance,
high hardness and mechanical strength
(3) Material transfer in case of DC is very low
(4) High electrical and thermal conductivity
(5) With very low arc erosion. On making higher current, normally asymmetric pairs
with AgC contact materials are applied
6) Wire of solid and composite rivets produced by powder sintering-extruding methods
AgSnO2 sheet
(1) AgSnO2 is the ideal material of AgCdO and has excellent properties of contacts
(2) AgSnO2 has higher thermal stability
(3) AgSnO2 has higher resistance against welding and erosion than AgCdO material
(4) Non-poisonous. So it is a new material which is empoldered and developed actively over the world
(5) For AgSnO2 contact material, the contact resistance can be controlled within
thelimited range by putting in a small amount of additive of special metal-oxide
(6) In this aspect, contact materials produced by powder metallurgy processing method have higher resistance against arc erosion and less arc bumming than those produced by oxidation processing method
AgZnO sheet
(1) ZnO, one type of material in AgznO contact, has comparatively higher thermalstability
(2) The welding resistant and resistance against arc erosion of the contact is better
(3) The AgZnO contact material has higher welding resistance and low arc erosion
with strong magnetic arc blowing under large switching capacity
(4) AgZnO contact material is innocuous and has no pollution to the environment
(5) AgZnO contact material is mostly suitable for contactors and circuit breakerswith
large capacities
AgCdO sheet
(1) AgCdO is a kind of most important contact material among silver metal-oxide materials, and it is widely used for low-voltage devices
(2) When the temperature is higher than 900centigrade, CdO is sublimated and the contact surface is cooled down in order to reduce and even extinguish
the arc energy. This method can increase the resistance against welding
(3) Contact materials produced by powder sintering-extruding methods have higher
density and low resistance rate
(4) It also has higher welding resistance and uniform arc erosionInner
2:type: Round type/ rectangular type,head dimension: round tip:2mm-25mm
rectangular tip: W=3mm-20mm,L=3mm-25mm;tip thickness:0.5mm-3.0mm
3:application: Highmediumlow voltage breaker, automatic switch, highmediumand low voltage electrical appliance
4:Radius can be customers size.
5: Products range: wall switch, relay, breaker, thermostat, mid/low voltage switch
6: ROHS compliance: as per customers requirement
7: Customized OEM/ODM orders are welcome: Yes
8: Resistant to high-current, high current, Kang Da current corrosion and welding, hardness, strength is higher than normal contacts
Our factory:
Contact sheet:
Certificate of Contact Sheet:
VARIOUS RIVETS CAN BE PRODUCED ACCORDING TO CUSTOMER'S REQUIREMENT
We look forward to build a long term relationships with you. If you have any questions, Please feel free to contact us! Also FREE SAMPLE can be sent for your evaluation!
