Specifications
UHF tag on Metal IP68 PCB - Fixed Asset Management-4-10m distance
-Best Equipment asset management
-Tracking,Logistic
IP68 Fixed Asset Management PCB UHF RFID metal tag
Feature:
- Independent R&D team. Completely self-owned technology.
- Up to 4-12m reading distance (2time of regular metal tag)
- Frequency Hopping working mode, with strong anti-jamming ability
- Passive UHF type, cost-effective solution
- Heat-resisting engineering material ABS. High quality apply to kinds of severe environment
Application:
- Warehousing Management / Equipment Inventroy
- Large Fixed-asset Management
- Manufacturing Process Tracking
- Express / Logistic / Seaport containers Mangement System
- IT asset management tracking, Item finding
- Supply Chain Control
- Security
- Electrombile/Car Mangement
Chinese No.1 UHF RFID long Range RFID manufacturer!!!
Specification:
Item No. |
W4280 |
Protocol |
EPC global C1 Gen2 / ISO 18000-6C |
Frequency |
920-925MHz, 902-928MHz, 865-868MHz Optional |
Working Mode |
Read/Write |
Modulation Mode |
FHSS |
Chip |
Impinj Monza 4QT (QStar optional) |
Housing Material |
PCB |
Read Range |
Fixed reader: 0-8 m, Handheld: 0-5m |
On Metal or Balanced |
On Metal and Balanced |
Size |
80 x 20 x 3 (mm) |
Weight |
8g |
User Memory |
EPC≥96bits, User Memory 512 bits |
Data Rate |
Forward: 40-160kbits/s, reverse:40-640kbits/s |
Data Protection |
Password modify, lock, kill |
Data-hold |
>10 years, Wipe more than 100000 times |
Ambient Temperature |
-40°C ~ 80°C |
IP Rate |
IP68 |
Shock and Vibration |
MIL STD 810-F ; BS EN 60068-2 |
Attachment |
with self adhesive (3M gum) |
Warranty |
60months |
Chinese the Best RFID high-tech production equipments!!!
We have very strict inspection process!!!!
Scan below QR code to contact Rodan now:
