Barcode scanner/ RFID handheld reader/WIFI reader

Specifications

Barcode RFID handheld reader Cost-efficient
-WinCE 6.0 optional.IP65,Small size
-1D/2D,HF/UHF,3G,GPS,Bluetooth

Cost-efficient Barcode RFID handheld reader

INTRODUCTION & FEATURE:

   Novelty, special, visual impact, elegant and refined appearance design cooperated with Red Dot Award winner company.

  Completely self-owned brand, independent R&D and patented product. Excellent human-computer interaction interface.

  Innovative ergonomic compact lightweight design, brings long time comfortable operation experience

  Industrial handheld mobile terminal by environmentally friendly hard-wearing materials.

IP65 rugged, 1.5m free drop tested, and applies to kinds of severe environment easily.

  7 main functions highly integrated: accurate Barcode Scanner (1D/2D), stable RFID (HF/UHF), GPS location, auto-focused Camera, multi choice wireless communication: WIFI, Bluetooth, and GPRS/GSM, supported and optional.

  Supports regions based on European RFID frequencies (Europe 865-868MHz ETSI EN 302 208) and US RFID frequencies

  Most competitive product in people management, electric power, energy and chemical industry, bank system, retails, manufacturing, fashion, express send-receive, logistics, hotel, safety, anti-counterfeiting and so on tracking management areas.



2^ND GENERATION INDUSTRIAL HANDHELD BARCODE TERMINAL

SPECIFICATIONS CHART:

System
Operation System:	Windows CE 6.0,Samsung 6410 ARM11 processor, 800MHz
Memory Capacity:	128MB DDR SDRAM,256MB ROM
Extended Memory:	2G/4G/8G/16G/32G SD
LCD Screen
Size:	3.5" 240*320 TFT LCD
Loudspeaker:	Built-in (Volume adjustable)
1D Barcode (standard) (2D barcode scanner optional)
Identify mode:	Laser Scan
Identify depth field:	45mm-450mm
1D Barcode type:	Code128.EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaba,China post 25,interteaved 2 of 5,ISBN/ISSN.Code93,etc
1D Barcode type:	PDF417, QR Code, Data Matrix, Aztec, Maxiccode. LP code, Chinese-sensible code, etc
UHF RFID ( optional, can’t be built-in with 2D barcode scanner at same time)
Protocol:	ISO18000-6C/EPC C1Gen2
Frequency:	860-960MHz,
Reading Distance:	0-1.5m
HF RFID (optional, can’t be built-in with UHF RFID at same time)
Protocol:	ISO14443A/B, ISO15693
Frequency:	13.56MHz,
Reading Distance:	0-8cm
GPS Location (optional)
Cold start time:	Within 45 seconds
Location precision:	Within 10 meters
Image Acquisition (optional)
Pixel:	3.2M pixel auto-focused
Wi-Fi (standard)
Protocol:	IEEE 802.11b/g
Distance:	100m indoor/300m outdoor
Receiver Sensitivity:	-75dBm
Transmitting Power:	within 100mW
Bluetooth (standard)
Protocol:	V2.0
GPRS/GSM/CDMA (optional)
GSM Bands:	850/900/1800/1900MHz
Interface
External port:	USB 2.0, RS232
Extend port:	1pcs SD/MMC card slot,1pcs SIM card slot,1pcs PSAM card slot
Battery parameter
Capacity	3.7V 4000mAh li-polymer battery
Operational environment
Working Temperature:	-20 - +55°C
Storage Temperature:	-30 - +60°C
Relative Humidity:	5%-95% RH  no condensing
Protection Grade:	IP65
Drop Test:	1.5 meter free fall into concrete
Physical parameter
Size:	160mm*77mm*30mm
Weight:	About 400 g

Chinese Most Complete RFID Production Base

MORE THAN 10 YEARS RFID R&D EXPERIENCE

For More Professional Before Sale / After Sale Service / Quality Warranty or Technology Support , please kindly email or call Rodan now. We will offer full solution to satisfy you.

Notes: This is a classic WinCE 6.0 OS version.



If your project need more commerical Android OS, you also can check below

W8700C HF RFID / Barcode Android 4.0 version
