New Product Remote GPS Handheld Rfid Reader With Gprs Module

New Product Remote GPS Handheld Rfid Reader With Gprs Module photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Operating System:
Other, Android
Processor Type:
Samsung
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Operating System Other, Android
Processor Type Samsung
Style Handheld Computer
Memory Capacity Other, 1G
Screen Size 3.5"
Weight 850g
Brand Name Huaxin Genvict
Model Number W8600 Android
Place of Origin Guangdong, China

Specifications

2014 new product handheld terminal RFID reader with UHF/HF/NFC function one year warranty
- Android 4.0 1.2m drop, IP65 rugged

      New product Remote GPS handheld rfid reader with gprs module













Product Description



  •   Patented high-end, imposing, visual impact and refined appearance design cooperated with famous industrial design company.
  •   Learned many advantages of similar products at home and abroad, abandoned the design flaws on the market in appearance, structure, performance, operation using and so on
  •   Completely self-owned brand, independent R&D team, and complete production line. Novelty, special, visual impact, atmospheric appearance design. Strong Battery, humanized hand trip brings long time comfortable operation experience.
  •   Android 4.0 Operation System, excellent human-computer interaction interface.
  •   Industrial device by environmentally friendly hard-wearing materials.
  • IP65 rugged, 1.2m free drop tested, and applies to kinds of severe environment easily.
  •   4 kinds of data capture (UHF/HF RFID, 1D/2D Barcode Scanner, GPS, Camera, 4 kinds of communication: WIFI, Bluetooth, GPRS/GSM ,USB optional
  •   Max RFID module and antenna completely self-developed. Chinese No.1 UHF RFID Long reading distance up to 3-8m (max 9-12m) - Keeps champion.
  •   Most competitive product in ITS ( Express Way, Parking Lot, Vehicle Checking Management); Enterprise (Business offices/carpeted spaces), Asset/IT management, File and document tracking, Item finding
  • people management, electric power, energy and chemical industry, bank system, retails, manufacturing, fashion, express send-receive, warehousing logistics (Production line; Warehouse aisles and loading docks) , hotel, safety, anti-counterfeiting and so on tracking management areas.



Specification



System

Operation System

Android  4.0

CPU

Samsung Exynos4412 Quad Core, Aprocessor, 1.4GHz

Memory Capacity

1GB DDR SDRAM, 4GB ROM

Extended Memory

2G/4G/8G/16G/32G SD

LCD Screen

Size

3.5"

Type

480*640 HD LCD (semi-permeable optionally for outdoor)

LED:

Three-color LED Status

Loudspeaker:

Could be intruded (built-in)

UHF RFID

Protocol:

 ISO18000-6C / EPC C1Gen2

Frequency:

USA 902-928MHz FCC part 15



Europe 865-868MHz ETSI EN 302 208



China 920-925MHz



Japan 952-954MHz



Other country frequency customizable

Antenna:

Circular 4dBi

Reading Distance:

0-8m

1D/2D Barcode

Identify mode:

Laser Scan

Identify depth field:

45mm-450mm

Barcode type:

 1D:Code128.EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaba,China post 25,interteaved 2 of 5,ISBN/ISSN.Code93,etc



2D:PDF417, QR Code, Data Matrix, Aztec, Maxiccode. LP code, Chinese-sensible code, etc

GPS Location

Cold start time:

Within 60 seconds

Location precision:

Within 10 meters

Image Acquisition

Pixel:

5.0M pixel auto-focused

Wi-Fi Communication

Protocol

IEEE 802.11b/g

Distance

100m indoor/300m outdoor

Bluetooth Communication

Protocol

V4.0

GPRS/GSM/CDMA/3G WCDMA

GSM Bands

850/900/1800/1900MHz

Interface

External port

USB 2.0, RS232

Extend port

1pcs SD/MMC card slot,1pcs SIM card slot,1pcs PSAM card slot

Battery parameter

Capacity

7.4V 3500mAh li-polymer battery

Operational environment

Working Temperature

-30 - +60°C

Storage Temperature

-40 - +85°C

Relative Humidity

5%-95% RH  no condensing

Protection Grade

IP65

Drop Test:

1.2 meter free fall into concrete

Physical parameter

Size

200mm*84mm*155mm

Hand Shank

110mm

Weight

850 g including hand shank

Parts

Cable

USB cable and adaptor

Charge

Adaptor and battery






Production Flow



  1ST GENERATION INDUSTRIAL HANDHELD MOBILE TERMINAL



  CE / CCC / IP65 CERTIFICATED



New product Remote GPS handheld rfid reader with gprs moduleNew product Remote GPS handheld rfid reader with gprs moduleNew product Remote GPS handheld rfid reader with gprs moduleNew product Remote GPS handheld rfid reader with gprs module



Company Information



Chinese the Best RFID high-tech production equipments!!!





New product Remote GPS handheld rfid reader with gprs module



    We have very strict inspection process!!!!





New product Remote GPS handheld rfid reader with gprs module

    Chinese Most Complete RFID Production Base

New product Remote GPS handheld rfid reader with gprs module

     MORE THAN 10 YEARS RFID R&D EXPERIENCE
