Specifications
Long Range UHF Handheld RFID Reader with one year warranty-WinCE 6.0
-3G WCDMA,GPRS,
- Fingerprint,Barcode,BT,GPS
Long Range UHF Handheld RFID Reader with one year warranty
- Powerful: Max RFID module and antenna, reading distance up to 12m (stable 5-7m)
- Classic: Widest used Windows CE 6.0 OS with Samsung ARM11 CPU warrant stable working
- Nice-looking: Refined appearance design cooperated with Red Dot Award winner company
- Excellent: Dual battery, dual color modeling, dual keyboard design optional
- Humanist: Innovative lightweight, hand grip with trigger ergonomic design
- Industrial:IP65 rugged, 1.2m free drop, applying to kinds of severe environment
- Multi-functional: 4 data capture and 4 data communication methods optional.
System | |
Operation System | Windows CE 6.0 |
CPU | Samsung 6410 ARM11 processor Samsung CPU, 800MHz |
Memory Capacity | 128MB DDR SDRAM,256MB ROM |
Extended Memory | 2G/4G/8G/16G/32G SD |
LCD Screen | |
Size | 3.5" |
Type | 240*320 Semi-permeable TFT LCD (visual under sunshine outdoor) |
LED: | Three-color LED Status |
Loudspeaker: | Could be intruded (built-in) |
1D/ Barcode | |
Identify mode: | Laser Scan |
Identify depth field: | 45mm-450mm |
Barcode type: | 1D:Code128.EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaba,China post 25,interteaved 2 of 5,ISBN/ISSN.Code93,etc |
UHF RFID | |
Protocol: | ISO18000-6C/EPC C1Gen2 |
Frequency: | 860-960MHz, |
| Country frequency customization optional |
Antenna: | Circular 4dBi |
Reading Distance: | 0-7m |
GPS Location | |
Cold start time: | Within 60 seconds |
Location Precision: | Within 10 meters |
Encryption |
|
PSAM module | ISO7816 |
Software Development | SDK DEMO available |
Image Acquisition | |
Camera Pixel: | 3.2M Pixel auto-focused |
Wi-Fi | |
Protocol | IEEE 802.11b/g |
Distance | 100m indoor/300m outdoor |
Receiver Sensitivity | -75dBm |
Transmitting Power | within 100mW |
Bluetooth | |
Protocol | Support versions 2.0 |
GPRS/GSM/CDMA/WCDMA | |
GSM Bands | 850/900/1800/1900/2100 MHz |
Interface | |
External port | USB 2.0, RS232 |
Extend port | 1pcs SD/MMC card slot,1pcs SIM card slot,1pcs PSAM card slot |
Battery parameter | |
Capacity | Main battery: 3.7V 3700mAh li-polymer battery Secondary battery: 3.7V 2000mAh li-polymer battery |
Operational environment | |
Working Temperature | -20 - +55°C |
Storage Temperature | -30 - +60°C |
Relative Humidity | 5%-95% RH no condensing |
Protection Grade | IP65 |
Drop Test: | 1.2 meter free fall into concrete |
Physical parameter | |
Size | 160mm*77mm*142mm |
Hand Shake | About 100mm |
Weight | About 650g |
Parts | |
Cable | USB cable and 5V/3A adaptor |
Charge | Adaptor and battery |
Application:
- Traffic (Express Way, Parking Lot): ETC (Electronic Toll Collection) , Vehicle Checking, Management
- Retail (Sales Floor; POS; backroom): Inventory/cycle counting, Automatic replenishment, Receiving/shrink control, Item finding
- Enterprise (Business offices/carpeted spaces), Asset/IT management, File and document tracking, Item finding
- Healthcare(Hospitals; clinics), Asset management (for high value critical assets), Patient tracking,, Item finding
- Manufacturing / Warehousing(Production line; Warehouse aisles and loading docks)
- Logistic / Supply Chain Express; Container tracking Inventory/cycle counting Receiving/shrink control Item finding
Chinese the Best RFID high-tech production equipments!!!
We have very strict inspection process!!!!
Chinese Most Complete RFID Production Base
MORE THAN 10 YEARS RFID R&D EXPERIENCE
Skype: sallie.yue
Tel: +8613560777749
Email: yuexf(at)
For More Professional Before Sale / After Sale Service / Quality Warranty or Technology Support , please kindly email or call Sallie now. We will offer full solution to satisfy you.
