Long Range Fixed UHF RFID Reader for Race Timming System-rfid Manufacturer

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Huaxin Genvict
Model Number	W7640

Long range UHF RFID reader
-Double Core,15m reading range
-GRPS,WIFI,RJ45,RS232,USB wireless communication
-Support 4antennas

Long range UHF RFID reader wireless RFID reader

Introduction & feature:

Double industrial CPU design, Keep high performance and 24hrs X 365days no crash
ISO18000-6C/6B protocols compatible
Special dynamic Q anti-collision algorithm brings out excellent multi tag function
9dBi specialized antenna, up to stable 12m-15m reading distance.
Split Type and standard installing design, Very convenient In Site Operation
IP65, Sturdy and durable because of high strength integrative cast aluminum body
-85dBm high sensitivity

Application:

Traffic (Express Way, Parking Lot): ETC (Electronic Toll Collection) , Vehicle Checking, Management
Retail (Sales Floor; POS; backroom): Inventory/cycle counting, Automatic replenishment, Receiving/shrink control, Item finding
Enterprise (Business offices/carpeted spaces), Asset/IT management, File and document tracking, Item finding
Healthcare(Hospitals; clinics), Asset management (for high value critical assets), Patient tracking,, Item finding
Manufacturing / Warehousing(Animal Mangagement system;Production line; Warehouse aisles and loading docks)
Logistic / Supply Chain Express; Container tracking Inventory/cycle counting Receiving/shrink control Item finding

We have very strict inspection process!!!!

Specification:

CPU:		Double CPU design
Chip:		Special High performance Impinj UHF RIFD chip
	Working Voltage:	3.7V – 5 V
	Standby Current:	<50mA (EN Feet high level))
	Sleep Current:	<100uA (EN feet low level)
	Working Current:	1.2A +/-10%
	Working Temperature:	- 20 °C - + 55 °C
	Storage Temperature:	- 20 °C - + 85 °C
	Relative Humidity:	< 95% ( + 25 °C)
	Interface Protocol:	EPC global UHF Class 1 Gen 2 / ISO 18000-6C ISO 18000-6B
	Frequency Range:	860Mhz – 960Mhz
	Working Area supported:	US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Mainland China Japan, Korea, Malaysia, Taiwan
	Output Power:	20 – 33dBm
	Power Precision:	+/- 1dB
	Power Flatness:	+/- 0.2dB
	Receiving Sensitivity:	< -85 dBm
	Inventory Peak Speed:	> 500pcs
	Tags Buffer Cache:	800pcs @ 96 bit EPC
	Tag RSSI	Supported
	Antenna Connection Protection:	Supported
	Temperature Monitoring:	Supported
	Working Mode:	Single/Intensive Mode
	Communication Interface:	TTL UART(RS232) Interface
	GPIO	2 input, 2 output (3.3V level)
	Baud Rate	115200 bps
	Heat-dissipating Method:	External cooling fin

If you still have any RFID application questions, email or call Tina now. I will give you best answer.
