Specifications
IP65 Android Fingerprint Device - 2014 New Portable Reader-3G GPS BT UHF HF RFID Barcode
-FAR<0.001%
-4.0 OS,1.5m free test
IP65 Android Fingerprint Device - 2014 New Portable Reader
2ND GENERATION INDUSTRIAL HANDHELD BIOMETRIC INDENTIFICATION TERMINAL
SPECIFICATIONS CHART:
System | |
Operation System: |
Android 4.0,Multi-language |
CPU: |
Samsung Exynos4412 Quad Core, ARM 9 processor, 1.4GHz |
Memory Capacity: |
1GB DDR SDRAM, 4GB ROM |
Extended Memory: |
2G/4G/8G/16G/32G SD |
LCD Screen | |
Size: |
3.5" 480*640 HD LCD |
Loudspeaker: |
Built-in (Volume adjustable) |
Biometric Identification (standard) | |
Fingerprint Sensor: |
Capacitance |
Registration Time: |
<3s |
FAR: |
<0.001% |
1D Barcode (optional) | |
Identify mode: |
Laser Scan |
Barcode type: |
Code128.EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaba,China post 25,interteaved 2 of 5,ISBN/ISSN.Code93,etc |
UHF RFID (optional) | |
Protocol: |
ISO18000-6C/EPC C1Gen2 |
Frequency: |
860-960MHz, |
Antenna: |
Circular 2dBi |
Reading Distance: |
0-1.5m |
HF RFID (optional, can’t be built-in with UHF RFID at same time) | |
Protocol: |
ISO14443A/B, ISO15693 |
Frequency: |
13.56MHz, |
Reading Distance: |
0-8cm |
GPS Location | |
Cold start time: |
Within 60 seconds |
Location Precision: |
Within 10 meters |
Image Acquisition(optional) | |
Pixel: |
5.0M Pixel auto-focused |
Wi-Fi (standard) | |
Protocol: |
IEEE 802.11b/g |
Distance: |
100m indoor/300m outdoor |
Receiver Sensitivity: |
-75dBm |
Transmitting Power: |
within 100mW |
Bluetooth (standard) | |
Protocol: |
V 4.0 |
GPRS/GSM/CDMA/WCDMA(standard, optional in bulk order) | |
3G Bands: |
850/900/1800/1900/2100MHz |
Interface | |
External port: |
USB 2.0, RS232 |
Extend port: |
1pcs SD/MMC card slot,1pcs SIM card slot,1pcs PSAM card slot |
Battery parameter | |
Capacity: |
3.7V 4000mAh li-polymer battery |
Operational environment | |
Working Temperature: |
-20 - +55°C |
Storage Temperature: |
-30 - +60°C |
Relative Humidity: |
5%-95% RH no condensing |
Protection Grade: |
IP65 |
Drop Test: |
1.5 meter free fall into concrete |
Physical parameter | |
Size: |
160mm*77mm*37mm |
Weight: |
About 450g |
Chinese Most Complete RFID Production Base
MORE THAN 10 YEARS RFID R&D EXPERIENCE
For More Professional Before Sale / After Sale Service / Quality Warranty or Technology Support , please kindly email or call Lucky now. We will offer full solution to satisfy you
Notes: W8700B is a new industrial / rugged/ power handheld device mainly focused on Biometric Identification FINGERPRINT
If your project have other main demand such us UHF HF RFID, BARCODE .Welcome to have a look at our new models in same series as below.
W8700A UHF RFID with grip trigger design
W8700C HF RFID / Barcode version
