Specifications
2013 New WinCE Barcode Scanner - Big Promotion-Rugged IP65,Stable OS,
-Symbol 1D
-RFID,GPS,GPRS,BT,Camera options
-25% OFF
2013 New WinCE Barcode Scanner - Big Promotion
NEW 2nd Generation Mobile Handheld Terminal on Sale!!!
Promotion:
- Only For Oversea Clients: Out of Chinese Mainland. HongKong, Macau, Taiwan Clients also most welcome
- W8700C WinCE+WiFI +1D scanner 25% OFF
- Each Order Not More than 30pcs, each Client Not More than 2 times at this price
- Time Limit: 2013-9-10 to 2013-12-31
After this time, we will follow new pricing list
Feature:
- Novelty, special, visual impact, 640*480 HD touch screen. Elegant and refined appearance design cooperated with Red Dot Award winner company.
- Completely self-owned brand, independent R&D and patented product. Excellent human-computer interaction interface.
- Industrial handheld mobile terminal by environmentally friendly hard-wearing materials.IP65 rugged, 1.5m free drop test.
- 7 main functions highly integrated: accurate Barcode Scanner (1D/2D), stable RFID (HF/UHF), GPS/Beidou double location modes, auto-focus 5.0MP Camera, multi choice wireless communication: WIFI, Bluetooth, GPRS, supported and optional.
- Supports regions based on European RFID frequencies (Europe 865-868MHz ETSI EN 302 208) and US RFID frequencies
- Most competitive product in express send-receive, logistics, retail, anti-counterfeiting and so on tracking management areas.
Application:
- Traffic (Express Way, Parking Lot): ETC (Electronic Toll Collection) , Vehicle Checking, Management
- Retail (Sales Floor; POS; backroom): Inventory/cycle counting, Automatic replenishment, Receiving/shrink control, Item finding
- Enterprise (Business offices/carpeted spaces), Asset/IT management, File and document tracking, Item finding
- Healthcare(Hospitals; clinics), Asset management (for high value critical assets), Patient tracking,, Item finding
- Manufacturing / Warehousing(Production line; Warehouse aisles and loading docks)
- Logistic / Supply ChainExpress; Container tracking Inventory/cycle counting Receiving/shrink control Item finding
System | |
Operation System |
Windows CE 6.0 |
CPU |
ARM11 processor Samsung CPU, 800MHz |
Memory Capacity |
128MB DDR SDRAM,256MB ROM |
Extended Memory |
2G/4G/8G/16G/32G SD |
LCD Screen | |
Size |
3.5" |
Type |
Semi-permeable TFT LCD (visual under sunshine outdoor) |
LED: |
Three-color LED Status |
Loudspeaker: |
Could be intruded (built-in) |
1D/2D Barcode | |
Identify mode: |
Laser Scan |
Identify depth field: |
45mm-450mm |
Barcode type: |
2D:PDF417,QR Code, Data Matrix, Aztec, Maxiccode. LP code, Chinese-sensible code, etc |
|
1D:Code128.EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaba,China post 25,interteaved 2 of 5,ISBN/ISSN.Code93,etc |
UHF RFID | |
Protocol: |
ISO18000-6C/EPC C1Gen2 |
Frequency: |
860-960MHz, |
|
Country frequency customization optional |
Antenna: |
Circular 2dBi |
Reading Distance: |
0-1.5m |
HF RFID | |
Protocol: |
ISO14443A/B, ISO15693 |
Frequency: |
13.56MHz, |
Reading Distance: |
0-10cm |
GPS Location | |
Cold start time: |
Within 60 seconds |
Location Precision: |
Within 10 meters |
Encryption |
|
PSAM module |
ISO7816 |
Software Development |
SDK DEMO available |
Image Acquisition | |
Pixel: |
5.0M Pixel auto-focused |
Night Vison Image |
1.0M Pixel |
Night Vision Range |
3-5 meters |
Wi-Fi | |
Protocol |
IEEE 802.11b/g |
Distance |
100m indoor/300m outdoor |
Receiver Sensitivity |
-75dBm |
Transmitting Power |
within 100mW |
Bluetooth | |
Protocol |
Support versions 2.0 |
GPRS/GSM/CDMA | |
GSM Bands |
850/900/1800/1900MHz |
Interface | |
External port |
USB 2.0, RS232 |
Extend port |
1pcs SD/MMC card slot,1pcs SIM card slot,1pcs PSAM card slot |
Battery parameter | |
Capacity |
3.7V 4000mAh li-polymer battery |
Operational environment | |
Working Temperature |
-20 - +55°C |
Storage Temperature |
-30 - +60°C |
Relative Humidity |
5%-95% RH no condensing |
Protection Grade |
IP65 |
Drop Test: |
1.5 meter free fall into concrete |
Physical parameter | |
Size |
160mm*77mm*30mm |
Weight |
300-450g(with different function modules) |
Parts | |
Cable |
USB cable and 5V/3A adaptor |
Charge |
Adaptor and battery |
Chinese No.1 UHF RFID long Range RFID manufacturer!!!
Chinese the Best RFID high-tech production equipments!!!
We have very strict inspection process!!!!
MORE choices Please kindly search: W8700A, W8700B , W8600
(Android OS version device promotion will start from End of October,to be expected~!!)
