Suitable big farm Hydraulic no till wheat seeder with 3 point linkage
Mached power over 50HP
Double dics opener controled by hydraulic systerm
Factory price with fastest delivery
Introduce details
1) it is suitable for seeding wheat, rice, soybean, millet, sesame, alfalfa and sorghum etc
2) the furrow opener is adopted double discs, double bearings
3) it can complete ditching, fertilizing, seeding, covering and pressing during one operation
4) the parts and main frame adopt bolting connection, which is reliable and convenient to assemble
5) furrow opener and roller controlled by hydraulic system
6) inflatable gound-wheel can improve seeding speed
Specification
Model |
2BFY-24 |
2BFY-28 |
2BFY-36 |
Overall Dimensions(mm) |
3760×7360×1660 |
3760×7960×1660 |
4360×9780×1660 |
Net Weight(kg) |
1450 |
1700 |
2250 |
Working Width(mm) |
3600 |
4200 |
5400 |
Working Depth(mm) |
30-80 |
30-80 |
30-80 |
Driving Power(hp) |
50-80 |
60-130 |
75-180 |
Type of transmission |
Chain Transmission |
Chain Transmission |
Chain Transmission |
Volume of Fertilizer Box(L) |
430 |
500 |
645 |
Volume of Seeds Box(L) |
410 |
480 |
615 |
Type of Seeds Discharger |
Cast Iron Flute Wheel |
Cast Iron Flute Wheel |
Cast Iron Flute Wheel |
working efficiency(Ha/h) |
2-2.86 |
2.52-4.2 |
3.24-5.4 |
Spaces between Rows(mm) |
150(adjustable) |
150(adjustable) |
150(adjustable) |
Working Speed(km/h) |
7-10 |
6-10 |
7-10 |
Type of Openers |
Double-disc |
Double-disc |
Double-disc |
|
Distance between front and back Openers(mm) |
260 |
260 |
260 |
Type of Clutch |
jaw(teeth) positive-contact type |
jaw(teeth) positive-contact type |
jaw(teeth) positive-contact type |
Packing
1. All machines, which is less than a full container, are packed by the standard wooden case for exporting. So it is safe and strong enough for a long journey from our factory to your place.
2. If all the machines are shipped by a full container, the container will be loaded in our factory by our workers. Also, all the machines will be fixed onto the container.
Delivery
1. The machine will be sent to you by sea, by air or even by International courier service.
2. The dievery time is usually 20-25 days upon receipt of your depoist.
Different type agricultural seeder machine for customer's choose
