fiber laser marking machine
Specification
Model |
ST-MF10/20/30/50 |
Laser Type |
Fiber laser |
Marking Range |
160×160mm |
Laser Power |
10W/20W/30W/50W |
Laser Wavelength |
1064nm |
Lifting table |
Electric up-down |
Marking Speed |
≤7000mm/s |
Marking depth |
≤0.5mm |
Minimum Marking Character |
0.1mm |
Minimum Line Width |
0.01mm |
Resetting Positioning |
±0.01mm |
Power Supply |
220V 50HZ |
Gross Power |
≤1000W |
Gross Weight |
200 kgs |
Machine Dimension |
1300*1100*1130mm |
Applicable industries:
Integrated circuits, Medical instruments, Hardware tools, Jewelry, Craft gifts, Clocks and glasses, Clothing industry, Communication products, Plastic products, Electronic components, Auto parts, Building materials, Nameplates etc
Working samples
Features:
1. Adopt fiber laser, then through the high-speed galvanometer scanning system.
2. Fiber laser marking machine has a high electro-optic conversion efficiency, with good beam quality and high stability & reliability.
3. Fully air cooling, 100000 hours working life, Maintenance-free, Low cost, Energy-saving.
4. Applied for the metal and non-metal materials, like hardware parts, plastic keys etc.
5. Marking environmental protection, comply with ROHS standard.
Advantages:
1. Develop the software and marking card independently, and customize the software quickly.
2. Support offline marking, no need computer when working, save the energy, electricity, and cost.
3. Perfect marking effect, optimize the engraving effect according to the demand of customers from different industries.
4. Many kinds of drawing processing methods are optional, with high-speed marking, high efficiency, and good effect.
Payment
1) We accept T/T, Western union etc, if you want to use other way,please contact us.
2) We will start to prepare your order after you make the payment.
Shipping
We will send out the machine by Sea to the nearest port in your country.
If you want to send it by DHL or any other shipping way,please contact us in advance.
For shipping purpose, please tell us your phone number and detailed contact information after you confirm the order.
Warranty
1) The warranty for the whole machine is 12 months.
2) The warranty for fiber laser is 24 months.
3) The warranty is from the date of arriving at the port of destination.
4) During the warranty, we will repair the broken parts for FREE.
5) When the warranty is over, we will charge for the repair.
6) If there's any problem in the future, we will give you tech support by sending email/telephone/skype/msn and we will send you tech documents to fix the problems soon.
