Grade A Cells 60w 70w 80w 100w Solar Panel Manufaturers in China
US$ 50 - 120
/ Piece
1 Piece(Min. Order)
- Guangzhou port
- Credit Card
You May Like
-
High Quality pv Solar 3w 5w 10w 15w 20w Panel Wholesales
-
Competitive Price 300w Solar pv Panels for Sale Quality Choice
-
China Brand Solar Panel Wholesale China, Home Panel 150w
-
Good Price 300w Solar pv Panel Use for Solar System 5000w
-
Best Price Mono and Poly Solar Panel 18v36v 3-300w for Home Use Quality Choice
-
PV Solar Cells 100w 150w 250w 300w Solar Panel
Product Details
| Place of Origin | Guangdong, China | Brand Name | CAP | |
| Model Number | 100w 150w 200w 250w 300w | Material | Monocrystalline Silicon | |
| Size | 1470*680*35mm | Number of Cells | 36&72 | |
| Max. Power | 300w |
Product Description
grade A cells 60w 70w 80w 100w solar panel manufaturers in china
Characteristic:
1.High reliability with guaranteed ± 3% output power tolerance.
2.The modules can withstand high wind-pressure, snow loads and extreme temperatures
3.Bypass diodes to minimize power loss with shading
4.High and stable conversion efficency to ensure the highest quality
5.High efficiency,waterproof ,stand heavy rain and snow
| Model | Peak Power Pm(W) | Maximum Power Voltage Vm(V) | Maximum Power Current Im(A) | Open Circuit Voltage (Voc)V | Short Circuit Current Isc(A) | 1580 |
| CY-TD03-6 | 3 | 9 | 0.34 | 10.62 | 0.36 | 240*165*25 |
| CY-TD05-6 | 5 | 9 | 0.56 | 10.62 | 0.61 | 270*235*25 |
| CY -TD10 | 10 | 18 | 0.55 | 21.24 | 0.6 | 350*290*25 |
| CY -TD15 | 15 | 18 | 0.84 | 21.24 | 0.91 | 420*350*25 |
| CY -TD20 | 20 | 18 | 1.12 | 21.24 | 1.22 | 535*350*35 |
| CY -TD25 | 25 | 18 | 1.39 | 21.24 | 1.52 | 525*445*35 |
| CY -TD30 | 30 | 18 | 1.67 | 21.24 | 1.83 | 535*515*35 |
| CY -TD35 | 35 | 18 | 1.95 | 21.24 | 2.13 | 625*535*35 |
| CY -TD40 | 40 | 18 | 2.23 | 21.24 | 2.45 | 625*535*35 |
| CY -TD50 | 50 | 18 | 2.78 | 21.24 | 3.05 | 805*535*35 |
| CY -TD55 | 55 | 18 | 3.06 | 21.24 | 3.36 | 805*535*35 |
| CY -TD60 | 60 | 18 | 3.34 | 21.24 | 3.66 | 805*535*35 |
| CY -TD70 | 70 | 18 | 3.89 | 21.24 | 4.27 | 1190*540*35 |
| CY -TD75 | 75 | 18 | 4.17 | 21.24 | 4.58 | 1190*540*35 |
| CY -TD80 | 80 | 18 | 4.45 | 21.24 | 4.88 | 1190*540*35 |
| CY -TD85 | 85 | 18 | 4.73 | 21.24 | 5.19 | 1190*540*35 |
| CY -TD100 | 100 | 18 | 5.56 | 21.24 | 6.1 | 1060*805*35 |
| CY -TD120 | 120 | 18 | 6.67 | 21.24 | 7.33 | 1060*805*35 |
| CY -TD130 | 130 | 18 | 7.23 | 21.24 | 7.9 | 1480*680*35 |
| CY -TD150 | 150 | 36 | 4.17 | 42.48 | 4.58 | 1580*805*50 |
| CY -TD160 | 160 | 36 | 4.45 | 42.48 | 4.88 | 1580*805*50 |
| CY -TD165 | 165 | 36 | 4.59 | 42.48 | 5.04 | 1580*805*50 |
| CY -TD170 | 170 | 36 | 4.73 | 42.48 | 5.19 | 1580*805*50 |
| CY -TD175 | 175 | 36 | 4.86 | 42.48 | 5.34 | 1580*805*50 |
| CY -TD180 | 180 | 36 | 5.00 | 42.48 | 5.5 | 1580*805*50 |
| CY -TD190 | 190 | 46.46 | 4.09 | 57.12 | 4.41 | 1580*1050*50 |
| CY -TD200 | 200 | 46.46 | 4.30 | 57.12 | 4.65 | 1580*1050*50 |
| CY -TD210 | 210 | 46.46 | 4.52 | 57.12 | 4.88 | 1580*1050*50 |
| CY -TD220 | 220 | 46.46 | 4.09 | 57.12 | 4.41 | 1580*1050*50 |
| CY -TD230 | 230 | 36 | 6.39 | 42.48 | 7.02 | 1950*995*50 |
| CY -TD250 | 250 | 36 | 6.95 | 42.48 | 7.64 | 1950*995*50 |
| CY -TD260 | 260 | 36 | 7.23 | 42.48 | 7.94 | 1950*995*50 |
| CY -TD280 | 300 | 36 | 7.78 | 42.48 | 8.55 | 1950*995*50 |
