Features:
1.Standard design, which using the most common spiral nozzle;
2.Many kinds of angles and flow rates available;
3.Fine uniform aerosol effect;
4.Free passage design minimizes clogging;
5.3/8 inches to 4 inches, available to thread, flange or winding connection;
6.Silicon Carbide (SiC): high efficiency, corrosion resistance, wear resistance, high temperature tolerance
Common Applications:
Flue Gas Washing
Gas Cooling
Washing and Rinsing
Fire Prevention&Fire Suppression
Desulphurization nozzle is mainly used in the power plant or boiler
As a professional nozzle provider for flue gas desulfuration system , we have rich experience in spray application and operations , we are able to provide a variety of products with high reliable performance and strong technical supports as well as prefect after service .
Spiral nozzle is one of the most unique nozzles, with the spiralling gradient body, the limestone slurry is constantly tangent with the spiral line , and then changing direction and cutting into co-axle cone, with very free flow throughout the body till exit. Even under low operating pressure, it still has a high absorption efficiency; it therefore is widely recognized by in desulfuration system .
| Technical Parameter of Reaction Bonded Silicon Carbide | |
| item | data |
| temperature of application | 1380°C |
| density | >=3.02g/cm3 |
| open porosity | <0.1% |
| bending strength | 250Mpa(20centigrade), 280Mpa(1200centigrade) |
| modulus of elasticity | 330Gpa(20centigrade), 300Gpa(1200centigrade) |
| thermal conductivity | 45W/m.k(1200centigrade) |
| coefficient of thermal expansion | 4.5K-1*10-6 |
| Mohs hardness | 13 |
| Acid and alkali resistance | Excellent |
Packaging: standard export wooden case and pallet
Shipping: by ship as per your order quantity
1. Provide sample for test before order
2. Arrange production on time
3. Control quality and production time
4. Provide finished products and packing photots
5. Delivery on time and provide original documents
6. After sale service
7. Continous competitive price
Weifang Better Machinery Co., Ltd. is a professional silicon carbide products research and development, production and sales of the manufacturers , to professional , as the international business-oriented high-end silicon carbide ceramics production enterprises.
SiC desulphurizing nozzles can serve a long time ,about 10~20 times longer than common metal ,4~7 times longer thanalumia,especially suitable to serve in harsh conditions.SiC nozzles are key components of the complete set of equipment for dust removal,desulfurization and denitration in coal-fired power plants,steel mills,large boiler and other large coal-fired equipments.
We specialize in the production of silicon carbide nozzles. All the products can be customized according to your requirements.We are wholehearted to provide you with high quality silicon carbide nozzles.
