2013 New style Fanless True flat touch screen all in one computer for POS system

Board

CPU

INTEL® Cedar Trail-D Processor N2600 1.6GHz with L2 Cache 1MB

Chipset

INTEL®NM10 Express chipset

System Memory

1 x SO-DIMM DDRIII 2G , up to 4GB

Display

TFT LED

38.1cm (15")

Brightness

350nits

Resolution

1024 x 768

Touch Screen

True Flat Projected Capacitive Technology / True Flat 5-Wire Resistive

Storage

HDD Type

1 x SATA 6.4cm (2.5'')HDD

SSD Type

1 x SATA 6.4cm (2.5”) SSD (optional)

DC Input

1 x Mini Din 2P (DC 12V only)

I/O Ports

External

Network (LAN)

1 x Gigabit Ethernet by RJ-45

USBPort

4 x USB 2.0

SerialPort

4 x RS-232 w/ IR/5V/12V power

Audio

1 x Line-out ; 1 x Mic-In (optional)

PS/2 Port

1 x PS/2 connector for Keyboard

LPTPort

1 x DB-25 PrinterPort (Standard)

VGA Port/HDMI

1 x DB-15 VGA Port (optional)

Power Supply

External adapter, DC Model:80 Watts, Voltage:+12VDC 5.0A max.

Color

Main Unit: Gray / White / Black
Customized color for plastic parts

VESA Mounting

100 x 100 mm

Operating Temperature

0ºC ~ 40ºC, 10% ~ 90% RH, non-condensing

Storage Temperature

-20ºC ~ 60ºC, 10% ~ 90% RH, non-condensing

Certifications

CCC,CE, FCC, RoHS

OS Support

Windows 7, Windows POSReady, Windows XP Pro for Embedded,WinCE, Fedora(Linux)

Dimension( Wx H x D )

370 x 300 x 236 mm

Weight

5.7 Kg
(Aluminium Base: 1 Kg )
