Copper / Aluminum Wire Washing Machine Wash Motor

Copper / Aluminum Wire Washing Machine Wash Motor photo-1
US$ 4.9 - 7.9 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
juhong
Model Number:
XD-150
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name juhong
Model Number XD-150

Specifications

1.Type: Washing Machine Parts
2.Place of Origin: Zhejiang China (Mainland)
3.Brand Name:Juhong
4.High quality,low price

specification :

 AUTO motor

1,model: XD-150(from 90W-300W)

2,power :150W

3,volatge:220V/230V/240V 127V

4,frequency:50hz/60hz

5,runing direction: CCW/CW

6,capacitor: 10uf/12uf

7,speed:1320rpm/min

8,gurtantee times:3years



twin tube wash machine motors

Our company was established in 1994,it occupied a land area of 20280 square meters and specialized in micro-motors manufacturing. Owing good service,variety of high quality products and competitive price. and efficient delivery,we have been enjoying a good reputation among our customers.



washing motors
model rated power voltage frequency current rating starting torque greatest torque
XD-80 80W 220-240v 110-127v 50/60Hz  60Hz <=0.85A       <=1.5A >=0.7Nm >=1.0Nm
XD-100 100W 220-240v 110-127v 50/60Hz  60Hz <=1.1A       <=2.2A >=0.8Nm >=1.30Nm
XD-120 120W 220-240v 110-127v 50/60Hz  60Hz <=1.15A       <=2.2A >=0.85Nm >=1.50Nm
XD-130 130W 220-240v 110-127v 50/60Hz  60Hz <=1.3A       <=2.5A >=0.90Nm >=1.55Nm
XD-150 150W 220-240v 110-127v 50/60Hz  60Hz <=1.4A       <=2.8A >=0.95Nm >=1.70Nm
XD-180 180W 220-240v 110-127v 50/60Hz  60Hz <=1.6A       <=3.5A >=1.2Nm >=2.30Nm
spin motor
model rated power voltage frequency current rating starting torque greatest torque
YYG-30 30W 220-240v 110-127v 50/60Hz  60Hz <=0.5A       <=0.95A >=0.32Nm >=0.45Nm
YYG-40 40W 220-240v 110-127v 50/60Hz  60Hz <=0.58A       <=1.10A >=0.38Nm >=0.50Nm
YYG-45 45W 220-240v 110-127v 50/60Hz  60Hz <=0.65A       <=1.3A >=0.42Nm >=0.56Nm
YYG-60 60W 220-240v 110-127v 50/60Hz  60Hz <=0.75A       <=1.5A >=0.50Nm >=0.75Nm
YYG-70 70W 220-240v 110-127v 50/60Hz  60Hz <=0.8A       <=1.5A >=0.53Nm >=0.82Nm
YYG-90 90W 220-240v 110-127v 50/60Hz  60Hz <=0.95A       <=1.8A >=0.63Nm >=1.10Nm

.



this is atuo washing mtor ,It's running common ,aslo have good performance in operation .we can do it from 90W-300W .
