Tiger Rig Trade Assurance PZ Series Mud Pump for Oil Well Drilling Rig
US$ 100 - 3,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
ocean renda
Model Number:
all
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PZ Series Triplex Mud Pump and PartsUS$ 100 - 3,000MOQ: 1 Piece -
3NB Series Triplex Mud Pump for Drilling RigUS$ 100 - 3,000MOQ: 1 Piece
-
API High Quality Drilling Portable PZ Mud PumpUS$ 100 - 3,000MOQ: 1 Piece
-
API High Quality Mud Pump for Drilling RigUS$ 500,000 - 800,000MOQ: 1 Set
-
API High Quality Mud Pump for Drilling Rig With Good PriceUS$ 500,000 - 800,000MOQ: 1 Set
Place of Origin
China
Brand Name
ocean renda
Model Number
all
Type
Other
Machine Type
Drilling Tool
Certification
API
Material
Carbon Steel
Processing Type
Casting
Use
Coal Mining
PZ Mud Pump
Specifications of PZ series oil well drilling mud pump
| Model | Max Input HP | Max RPM | Piston Cylinder | Displacement | Max PSI | Pump Weight | |||||
| Diameter | Per Revolution | Per Minute | |||||||||
| kg | |||||||||||
| PAH275 | 275 | 175 | in | mm | Gal. | L | Gal. | L/min | PSI | Kg/sq.cm2 | 4450 |
| 5* | 127 | 2.04 | 7.72 | 357 | 1,351 | 1,122 | 79 | ||||
| 4.5 | 114 | 1.65 | 6.25 | 289 | 1,094 | 1,386 | 97 | ||||
| 4 | 102 | 1.31 | 4.96 | 228 | 863 | 1,753 | 123 | ||||
| 3.5 | 89 | 1 | 3.79 | 175 | 662 | 2,290 | 161 | ||||
| 3.25 | 83 | 0.862 | 3.26 | 151 | 572 | 2,657 | 187 | ||||
| 3 | 76 | 0.734 | 2.79 | 128 | 485 | 3,118 | 219 | ||||
| PZ-7 | 550 | 145 | 7 | 178 | 3.5 | 13.25 | 507 | 1,919 | 1,673 | 118 | 7620 |
| 6.5 | 165 | 3.02 | 11.43 | 437 | 1,654 | 1,940 | 136 | ||||
| 6.25 | 152 | 2.78 | 10.55 | 404 | 1,530 | 1,100 | 148 | ||||
| 6 | 152 | 2.57 | 9.73 | 373 | 1,412 | 2,277 | 160 | ||||
| 5.5 | 140 | 2.16 | 8.18 | 313 | 1,185 | 2,710 | 191 | ||||
| 5 | 127 | 1.78 | 6.74 | 259 | 980 | 3,279 | 231 | ||||
| 4.5 | 114 | 1.45 | 5.49 | 210 | 795 | 4,048 | 285 | ||||
| 4 | 102 | 1.14 | 4.32 | 166 | 628 | 5,000 | 352 | ||||
| PZ-8 | 750 | 145 | 7 | 178 | 4 | 15.14 | 580 | 2,196 | 1,996 | 140 | 7900 |
| 6.5 | 165 | 3.45 | 13.06 | 500 | 1,893 | 2,315 | 163 | ||||
| 6.25 | 159 | 3.19 | 12.08 | 462 | 1,749 | 2,504 | 176 | ||||
| 6 | 152 | 2.94 | 11.13 | 426 | 1,613 | 2,717 | 191 | ||||
| 5.5 | 140 | 2.47 | 9.35 | 358 | 1,355 | 3,233 | 227 | ||||
| 5 | 127 | 2.04 | 7.72 | 296 | 1,120 | 3,912 | 285 | ||||
| 4.5 | 114 | 1.65 | 6.25 | 240 | 908 | 4,830 | 340 | ||||
| 4 | 102 | 1.31 | 4.96 | 189 | 715 | 5,000 | 352 | ||||
| PZ-9 | 1000 | 130 | 7 | 178 | 4.5 | 17.03 | 585 | 2,214 | 2,639 | 186 | 12890 |
| 6.5 | 165 | 3.88 | 14.69 | 504 | 1,908 | 3,060 | 215 | ||||
| 6.25 | 159 | 3.59 | 13.59 | 466 | 1,764 | 3,310 | 233 | ||||
| 6 | 152 | 3.3 | 12.49 | 430 | 1,628 | 3,592 | 253 | ||||
| 5.5 | 140 | 2.78 | 10.52 | 361 | 1,367 | 4,274 | 301 | ||||
| 5 | 127 | 2.29 | 8.67 | 298 | 1,128 | 5,000 | 352 | ||||
| 4.5 | 114 | 1.86 | 7.04 | 242 | 916 | 5,000 | 352 | ||||
| 4 | 102 | 1.47 | 5.56 | 191 | 725 | 5,000 | 352 | ||||
| PZ-10 | 1350 | 115 | 7 | 178 | 5 | 18.93 | 575 | 2,177 | 3,624 | 355 | 16815 |
| 6.5 | 165 | 4.31 | 16.32 | 496 | 1,878 | 4,203 | 295 | ||||
| 6 | 152 | 3.67 | 13.89 | 422 | 1,597 | 4,933 | 347 | ||||
| 5.5 | 140 | 3.09 | 11.7 | 355 | 1,344 | 5,000 | 352 | ||||
| PZ-11 | 1600 | 115 | 7 | 178 | 5.5 | 20.82 | 632 | 2,392 | 3,905 | 275 | 16815 |
| 6.5 | 165 | 4.74 | 17.94 | 545 | 2,063 | 4,529 | 318 | ||||
| 6 | 152 | 4.04 | 15.29 | 465 | 1,760 | 5,000 | 352 | ||||
| 5.5 | 140 | 3.4 | 12.87 | 390 | 1,476 | 5,000 | 352 | ||||
| 5 | 127 | 2.8 | 10.6 | 323 | 1,223 | 7,500 | 527 | ||||
